4. AC Smart II Menu
Unit operating mode display
AC SMART II displays the operating mode of each unit as the following icon.
When you set the information display format to ʻIconʼ, the screen will be displayed as follows.
Unit type
Indoor unit
Ventilator
Eco V DX
AWHP
When you set the information display format to ʻSimpleʼ, the screen will be displayed as follows.
Unit type
Indoor unit
Ventilator
Eco V DX
AWHP
Reference: On/Off unit operating mode
Unlike other units, the On/Off unit does not have any operating mode and the operating mode is
not displayed on the screen.
4-3
AC Smart
Icon Description
Cool mode
Dehumidifier
mode
Heating mode
Cool mode
Icon Description
Cool mode
Dehumidifier
mode
Heating mode
Cool mode
Icon Description
Heating
mode
Fan
mode
General
mode
Heating
mode
Icon Description
Heating
mode
Fan
mode
General
mode
Heating
mode
Icon Description
Auto mode
-
-
Auto mode
Auto mode
Icon Description
Auto mode
-
-
Auto mode
Auto mode
