10. Environment Setting

Screen calibration

To use AC SMART II, you must set all the information through the touch screen method. If the
coordinate that the user is operating is not aligned with the coordinate of the touch screen, AC SMART
II may not operate as intended by the user. In this case, you can reset the coordinates through touch
screen calibration.
When you press the ʻScreen calibrationʼ tab from the Environment Setting menu, you can calibrate the
touch screen.
Information: Using the external button of the AC Smart to calibrate
the screen
The screen calibration function can be executed by pressing [Backlight] button and [Keyboard]
button at once located at the top of the AC Smart. When you cannot perform this menu because of
the incorrect screen coordinate, use this method to calibrate the screen.
Keep the following steps to calibrate the screen of the AC Smart.
1
. When you press the ʻScreen calibrationʼ tab from the ʻEnvironment Settingʼ menu, the following
screen will be displayed. Press the [Screen calibration] button.
10-16
AC Smart
Press the [Screen
calibration] button
