just bought a used 08 B King and it will not start in neutral alone. you have to pull in the clutch lever and then it will start. I know thats not right. also on cold starts it acts like the choke is not activated. once it warms up it runs great

1 comments:

Mr. Anderson

February 10, 2025

The 2008 Suzuki GSX1300BK B King requires the clutch lever to be pulled in to start in neutral due to its interlock switches for the ignition and starter circuits. The engine can only be started if the transmission is in neutral and the clutch is disengaged, or if the transmission is in gear, the side stand is fully up, and the clutch is disengaged. This safety feature prevents accidental movement when starting.

Cold start issues occur because the engine requires proper fuel-air mixture and sufficient warmth to ignite efficiently. When the engine is cold, it may need additional throttle input (about 1/8 turn) to start. Letting the engine warm up after starting ensures smooth operation.

This answer is automatically generated

Summary of Contents for Suzuki GSX1300BK

Page 1 GSX1300BK OWNER’S MANUAL Part No. 99011-23H50-01A June, 2007...
Page 2 This manual should be considered a permanent part of the motorcycle and should remain with the motorcycle when resold or otherwise transferred to a new owner or operator. The manual contains important safety information and instructions which should be read carefully before operating the motorcycle.
Page 3 Proper break-in operation during this time will help ensure maximum life and perfor- mance from your new motorcycle. Suzuki parts are manufactured of high quality mate- rials, and machined parts are finished to close tolerances.
Page 4 Your authorized Suzuki dealer has experienced technicians CAUTION that are trained to provide your machine with the best possible service with the right tools These instructions point out special ser- and equipment.
Page 5 Please note that this manual applies to all specifications or all respective destinations and explains all equipment. Therefore, your model may have different standard features than shown in this manual. © COPYRIGHT SUZUKI MOTOR CORPORATION 2007...
Page 7 TABLE OF CONTENTS CONSUMER INFORMATION CONTROLS FUEL, ENGINE OIL AND COOLANT RECOMMENDATIONS BREAK-IN (RUNNING-IN) AND INSPECTION BEFORE RIDING RIDING TIPS INSPECTION AND MAINTENANCE TROUBLESHOOTING MOTORCYCLE CLEANING AND STORAGE PROCEDURE SPECIFICATIONS INDEX...
Page 9: Consumer Information
CONSUMER INFORMATION ACCESSORY USE AND MOTORCYCLE LOADING ................1-2 SAFE RIDING RECOMMENDATION FOR MOTORCYCLE RIDERS ............1-7 SERIAL NUMBER LOCATION ........................1-9 NOISE CONTROL SYSTEM (AUSTRALIA ONLY) .................. 1-10...
Page 10 Use extreme caution when selecting and install- ing the accessories on your motorcycle and consult your Suzuki dealer if you have any questions.
Page 11 Accessory installation guideline • Select an accessory which does not limit • Install aerodynamic affecting accesso- the freedom of rider movement. ries, such as a fairing, windshield, back- • Select an electric accessory which does rests, saddlebags, and travel trunks, as not exceed motorcycle’s electrical sys- low as possible, as close the motorcycle tem capacity.
Page 12 Loading Limit • Never exceed the G.V.W. (Gross Vehicle Weight) of this motorcycle. The G.V.W. is  WARNING the combined weight of the machine, accessories, payload and rider. When selecting your accessories, keep in mind Overloading or improper loading can the weight of the rider as well as the cause lose of motorcycle control and weight of the accessories.
Page 13 Loading Guidelines  WARNING • Balance the load between the left and right side of the motorcycle and fasten it Placing objects in the space behind the securely. fairing can interfere with steering and • Place cargo weight as close to the cen- can lose control.
Page 14 Suzuki will not be responsible in any way for personal injury or damage to the motorcycle caused by frame modifications. Bolt on accessories that do not modify the frame in any way may be installed provided that the GVW is not exceeded.
Page 15 SAFE RIDING INSPECTION BEFORE RIDING Review thoroughly the instructions in the RECOMMENDATION FOR “INSPECTION BEFORE RIDING” section of MOTORCYCLE RIDERS this manual. Do not forget to perform an Motorcycle riding is great fun and an excit- entire safety inspection to ensure the safety ing sport.
Page 16 KNOW YOUR LIMITS RIDE DEFENSIVELY Ride within the boundaries of your own skill The most common type of motorcycle acci- at all times. Knowing these limits and stay- dent occurs when a car traveling towards a ing within them will help you to avoid acci- motorcycle turns round corner in front of the dents.
Page 17 SERIAL NUMBER LOCATION The frame and/or engine serial numbers are used to register the motorcycle. They are also used to assist your dealer when order- ing parts or referring to special service infor- mation. The frame number 1 is stamped on the steering head tube.
Page 18 NOISE CONTROL SYSTEM (AUSTRALIA ONLY) TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED Owners are warned that the law may pro- hibit: (a) The removal or rendering inoperative by any person other than for purposes of maintenance, repair or replacement, of any device or element of design incorpo- rated into any new vehicle for the pur- pose of noise control prior to its sale or delivery to the ultimate purchaser or...
Page 19 KEY (Canada) ............................. 2-5 KEY (EU and Australia) ..........................2-6 IGNITION SWITCH ............................. 2-7 INSTRUMENT PANEL ..........................2-10 SUZUKI DRIVE MODE SELECTOR ......................2-32 LEFT HANDLEBAR ..........................2-34 RIGHT HANDLEBAR ..........................2-38 FUEL TANK CAP ............................2-42 GEARSHIFT LEVER ..........................2-44 REAR BRAKE PEDAL ..........................
Page 20 2 Left handlebar switches 9 INFO switch 3 Clutch fluid reservoir 0 SET switch 4 Instrument panel A Ignition switch 5 Front brake fluid reservoir B Fuel tank cap 6 Right handlebar switches C Suzuki drive mode selector 7 Throttle grip...
Page 21 D Helmet holder E Tools F Seat lock G Side stand H Gearshift lever...
Page 22 I Rear brake pedal...
Page 23 KEY (Canada)  WARNING Due to the location of the steering damper, some key chains could get caught between the steering damper and the steering stem nut. This could inter- fere with steering and cause loss of con- trol. Use your ignition key without key chains, fobs or other keys attached.
Page 24 KEY (EU and Australia)  WARNING Due to the location of the steering damper, some key chains could get caught between the steering damper and the steering stem nut. This could inter- fere with steering and cause loss of con- trol.
Page 25 Immobilizer identification code is pro- grammed into the key. Therefore, a key made by an ordinary locksmith will not work. Ask Suzuki dealer if you need to make a spare key. • If you loose the key, ask your Suzuki dealer to have the lost one deactivated.
Page 26: On Position
“LOCK” POSITION To lock the steering, turn the handlebar all the way to the left. Push down and turn the key to the “LOCK” position and remove the key. All electrical circuits are cut off. “ON” POSITION The ignition circuit is completed and the engine can now be started.
Page 27 “P” (Parking) POSITION When parking the motorcycle, lock the steering and turn the key to the “P” position. The key can now be removed and the posi- tion light and taillight will remain lit and the steering will be locked. This position is for night time roadside parking to increase visi- bility.
Page 28 INSTRUMENT PANEL The fuel injection system indicator light 3, coolant temperature indicator light 4, oil pressure indicator light D, LCD and meter needle work as follows to confirm their func- tion when the ignition switch is turned to the “ON” position. Align the lid hole position to the key hole position when inserting the key.
Page 29 TURN SIGNAL INDICATOR LIGHT 2 • The fuel injection system indicator light 3, coolant temperature indicator light When the turn signals are being operated 4, oil pressure indicator light D come either to the right or to the left, the indicator on for 3 seconds.
Page 30 COOLANT TEMPERATURE METER 5 The coolant temperature meter indicates engine coolant temperature. When the cool- ant temperature becomes high, the indicator light 4 comes on. 2-12...
Page 31 TACHOMETER 6 CAUTION The tachometer indicates the engine speed in revolutions per minute (r/min). Running the engine with high engine coolant temperature can cause serious engine damage. If the engine coolant temperature indicator light comes on, stop the engine to let it cool. Do not run the engine run until the cool- ant temperature indicator goes off.
Page 32 INFORMATION DISPLAY 7 The information display has four modes: 1. clock, odometer/trip meter, and fuel injection system indicator, 2. maintenance interval, 3. running time, 4. average speed. The infor- mation display will be changed by pushing the INFO switch on the fuel tank. 2-14...
Page 33 The display will be changed as shown above when the INFO switch is pushed. NOTE: Clock and trip meter can be adjusted only when the clock and odometer/trip meter is displayed. 2-15...
Page 34 NOTE: When the SEL button 1 and ADJ button 0 are held in, the display advances continuously. 4. Push the SEL button 1 and ADJ button 0, simultaneously for 2 seconds until return to the clock mode. Odometer/Trip Meter/ Fuel Injection System Indicator The indicator displays odometer/trip meter under normal condition.
Page 35 To change the display, push the SEL button NOTE: 1. The display changes in the order below. • Set the meter to odometer, then press and hold ADJ button 0 for 3 seconds to change between km/h and mph. (Except Odometer for Canada and Australia) •...
Page 36 Trip Meters The 2 trip meters are resettable odometers. They can register 2 kinds of distances at the same time. For instance, trip meter 1 can register the trip distance and trip meter 2 can register the distance between fuel stops.
Page 37 3 comes on and the display 7 and the display indicates “FI”, have your indicates “FI” in the odometer/trip meter dis- authorized Suzuki dealer or a qualified play area in the following 2 modes; mechanic inspect the fuel injection sys- tem as soon as possible.
Page 38 Suzuki dealer. If the engine stalls, try restarting the engine after turning the ignition switch off and on.
Page 39 If the display still indicates “CHEC” after checking the above items, inspect the igni- tion fuse and the connection of the lead wire couplers. When the display indicates “CHEC” in the odometer/trip meter display area, check fol- lowing items; • Make sure that the engine stop switch is in the “”...
Page 40 Maintenance Interval The maintenance interval display comes on to notify maintenance timing. Initial preset maintenance interval is 1000 km (600 miles). 2-22...
Page 41 M letter display come on to notify preset maintenance timing. Positive “M” mark and negative “M” mark comes on alternately when maintenance interval meter comes zero. Reset the display to turn off the “M” mark. To reset the maintenance interval: 1.
Page 42 To change the maintenance interval preset: 1. Turn on the ignition switch. Push INFO switch to indicate maintenance interval. 2. Push and keep both INFO switch and SET switch for more than 2 seconds. The display starts repeating positive “S” mark and negative “S”...
Page 43 Running Time To reset the running time: Running timer counts total time when the 1. Push the SET switch for more than 2 running time switch and ignition switch are seconds. Running time displays 00:00 turned on. The running time counts from when the running time is reset.
Page 44 Average Speed Average speed displays motorcycle average speed after the average speed switch and ignition switch is turned on. To turn on/off average speed: 1. Push SET switch to turn on the average speed counter. mark will start blink- ing. 2.
Page 45 To reset the average speed: Approximately Approximately 1. Push the SET switch for more than 2 Fuel tank Full 3.3 L 1.8 L seconds. Average speed displays – – –. Fuel gauge NOTE: Switching average speed will switch running time at the same time. Flicker FUEL METER 8 Flicker...
Page 46 IMMOBILIZER INDICATOR A (EU and Australia) The immobilizer indicator blinks 2 times when the ignition switch is turned on. Then indicator comes on 2 seconds and goes off. Immobilizer system is designed to help pre- vent motorcycle theft by electronically dis- abling the engine starting system.
Page 47 HIGH BEAM INDICATOR LIGHT B NOTE: • It is impossible to start the engine when This blue indicator light will be lit when the the indicator remains blinking. headlight high beam is turned on. • If the indicator remains blinking, it means NEUTRAL INDICATOR LIGHT C immobilizer system communication error between key and ECM or use of wrong...
Page 48 Check the oil level and make sure the proper amount of oil is in the engine. If the light still does not go out, have your autho- rized SUZUKI dealer or a qualified mechanic troubleshoot your motorcycle. 2-30...
Page 49 GEAR POSITION INDICATOR F The suzuki drive mode indicator displays The gear position indicator indicates gear drive mode; A or B. Refer to the SUZUKI position. This indicator displays “0” when the DRIVE MODE SELECTOR section for transmission is in neutral.
Page 50 Engine power characteristics ignition switch and the engine stop switch changed in 2 modes by operating the suzuki are turned on. Follow the procedure below drive mode selector to meet various riding to operate the suzuki drive mode selector. conditions and rider’s preference.
Page 51 NOTE: Drive Mode • Stop the motorcycle when operating the Engine power suzuki drive mode selector. The suzuki drive mode selector operation will be cancelled when the motorcycle is mov- ing. • The suzuki drive mode indicator blinks when drive mode change operation is failed.
Page 52 HEADLIGHT FLASHER SWITCH 2 LEFT HANDLEBAR Press the switch to flash the headlight high beam. The headlight high beam will be lit when the dimmer switch is in “LO” position. DIMMER SWITCH 3 “” position The headlight low beam and taillight turn on. “”...
Page 53 HAZARD WARNING SWITCH 4 CAUTION All four turn signal lights and indicators will flash simultaneously when the switch is Holding the dimmer switch between HI turned on with the ignition switch in the “ON” and LO position will light both HI and LO or “P”...
Page 54  WARNING Failure to use the turn signals, and fail- ure to turn off the turn signals can be hazardous. Other drivers may misjudge your course and this may result in an accident. Always use the turn signals when you intend to change lanes or make a turn.
Page 55 Clutch Lever Adjustment  WARNING Adjusting the clutch lever position while riding can be hazardous. Removing a hand from the handlebars can reduce your ability to control the motorcycle. Always keep both hands on the handle- bars while riding. The distance between the grip and the clutch lever is adjustable to 4 positions.
Page 56 FRONT BRAKE LEVER 2 RIGHT HANDLEBAR The front brake is applied by squeezing the brake lever gently toward the throttle grip. This motorcycle is equipped with a disk brake system and excessive pressure is not required to slow the machine down properly. The brake light will be lit when the lever is squeezed inward.
Page 57 Front Brake Lever Adjustment  WARNING Adjusting the front brake lever position while riding can be hazardous. Remov- ing a hand from the handlebars can reduce your ability to control the motor- cycle. Always keep both hands on the handle- bars while riding.
Page 58 NOTE: This motorcycle is equipped with interlock switches for the ignition circuit and the starter circuit. The engine can only be started if: • The transmission is in neutral and the clutch is disengaged, or • The transmission is in gear, the side stand is fully up and the clutch is disen- gaged.
Page 59 THROTTLE GRIP 4 CAUTION Engine speed is controlled by the position of the throttle grip. Twist it toward you to To prevent electrical system damage, do increase engine speed. Turn it away from not operate the starter motor more than you to decrease engine speed.
Page 60 FUEL TANK CAP To open the fuel tank cap, insert the ignition key into the lock and turn it clockwise. With the key inserted, lift up with the key and open the fuel tank cap. To close the fuel tank cap, push the cap down firmly with the key in the cap lock.
Page 61  WARNING  WARNING Overfilling the fuel tank can cause the Fuel and fuel vapor are highly flammable fuel to overflow when it expands due to and toxic. You can be burned or poi- heat from the engine or the sun. Spilled soned when refueling.
Page 62 GEARSHIFT LEVER NOTE: When the transmission is in neutral, the green indicator light on the instrument panel will be lit. However, even though the light is illuminated, cautiously and slowly release the clutch lever to make sure that the transmission is positively in neutral. Reduce the motorcycle speed before down- shifting.
Page 63 REAR BRAKE PEDAL SEAT LOCK AND HELMET HOLDER Front Seat Depressing the rear brake pedal will apply the rear disk brake. The brake light will be illuminated when the rear brake is operated. To remove the front seat, insert the ignition key into the lock and turn it clockwise.
Page 64 Helmet Holder This motorcycle has helmet holder under the front seat. To reinstall the seat, slide the seat hooks into the seat hook retainers and push down firmly until the seat snaps into locked posi- tion. Hook your helmet to the helmet holder and lock the seat.
Page 65  WARNING Riding with a helmet fastened to the hel- met holder can interfere with rider con- trol. Never carry a helmet fastened to the hel- met holder. Fix the helmet securely atop the seat if you must carry it. Use helmet holder wire as shown to hook passenger’s helmet.
Page 66 Rear Seat Raise the front end of the seat and slide it forward. The seat lock is located under the front seat. To remove the rear seat, pull the seat lock wire. 2-48...
Page 67 Seat Tail Cover A seat tail cover for solo riding can be attached by using the same procedure as for installing the rear seat. To reinstall the seat, slide the seat hooks into the seat hook retainers and push down firmly until the seat snaps into the locked position.
Page 68 LUGGAGE STRAPS SIDE STAND An interlock switch is provided to cut off the The luggage straps are folded under the ignition circuit when the side stand is down rear seat. Remove the straps from the hooks and the transmission is in any gear other and reinstall the rear seat with the straps than neutral.
Page 69 The side stand/ignition interlock switch CAUTION works as follows: • If the side stand is down and the trans- Park the motorcycle on firm, level mission is in gear, the engine can not be ground to help prevent it from falling started.
Page 70 SUSPENSION ADJUSTMENT FRONT SUSPENSION Spring Pre-load Adjustment The standard settings of both front and rear suspensions are selected to meet various riding conditions such as low to high motor- cycle speed and light to heavy load on the motorcycle. The suspension settings can be adjusted for your preference and fine-tuning.
Page 71 To change the spring pre-load, turn the adjuster 1 clockwise or counterclockwise. Turning the adjuster clockwise will increase the spring pre-load. Turning the adjuster counterclockwise will decrease the spring pre-load. There are 5 grooved lines on the side of the adjuster 1 for reference. Position 5 provides the minimum spring pre-load and position 0 provides the maximum pre-load.
Page 72 Damping Force Adjustment To set the rebound damping force adjuster The rebound and compression damping to the standard position, turn the adjuster force can be individually adjusted by turning clockwise until it stops and then turn it coun- the respective adjusters. The rebound terclockwise 9 clicks.
Page 73 Turn the adjuster clockwise from the stan- dard position to stiffen the damping force. Turn the adjuster counterclockwise to soften the damping force. The damping force should be adjusted gradually, 1 click at a time, to fine-tune the suspension. NOTE: Do not loosen the adjuster base 4, or front fork oil will ooze through the adjuster base.
Page 74 The adjustment can be performed by chang- ing the adjuster ring position. However, Suzuki recommends that this adjustment be done by your authorized Suzuki dealer, since a special tool is needed for this job.
Page 75 Turn the adjuster clockwise from the stan- dard position to stiffen the damping force. Turn the adjuster counterclockwise to soften the damping force. The damping force should be adjusted gradually, 1/8 turn at a time, to fine-tune the suspension. To set the rebound damping force adjuster to the standard position, turn the adjuster clockwise until it stops and then turn it coun- terclockwise 2 turns until the two punch...
Page 76 Turn the adjuster clockwise from the stan- dard position to stiffen the damping force. Turn the adjuster counterclockwise to soften the damping force. The damping force should be adjusted gradually, 1/8 turn at a time, to fine-tune the suspension. To set the compression damping force adjuster to the standard position, turn the adjuster clockwise until it stops and then turn it counterclockwise 2 turns until the two...
Page 77 FUEL, ENGINE OIL AND COOLANT RECOMMENDATIONS FUEL ................................3-2 ENGINE OIL ..............................3-4 COOLANT ..............................3-6...
Page 78 FUEL, ENGINE OIL AND NOTE: The GSX1300BK engine is designed to use premium unleaded gasoline only. Use COOLANT premium unleaded gasoline under all riding RECOMMENDATIONS conditions. FUEL NOTE: Oxygenated fuels are fuels which contain oxygen-carrying additives such as Use premium unleaded gasoline with an MTBE or alcohol.
Page 79 Suzuki and may not be covered under the as there are differences between brands. New Vehicle Limited Warranty or the Emis- sion Control System Warranty.
Page 80 ENGINE OIL SAE Engine Oil Viscosity Suzuki recommends the use of SAE 10W- Oil quality is a major contributor to your 40 engine oil. If SAE 10W-40 engine oil is engine’s performance and life. Always select not available, select an alternative according good quality engine oil.
Page 81 JASO T903 Energy Conserving The JASO T903 standard is an index to Suzuki does not recommend the use of select engine oils for 4-stroke motorcycle “ENERGY CONSERVING” oils. Some and ATV engines. Motorcycle and ATV engine oils which have an API classification engines lubricate clutch and transmission of SH or higher have an “ENERGY CON-...
Page 82 COOLANT CAUTION Use an anti-freeze compatible with alumin- ium radiator mixed with distilled water only Spilled engine coolant can damage at the ratio of 50:50. painted surfaces.  WARNING Do not spill any fluid when filling the radiator. Wipe spilled engine coolant up Engine coolant is harmful or fatal if swal- immediately.
Page 83 Water for mixing Required amount of water/coolant Use distilled water only. Water other than Solution capacity (total): 2900 ml distilled water can corrode and clog the alu- (3.1/2.6 US/Imp. qt) minium radiator. 1450 ml Water (1.5/1.3 US/Imp. qt) Anti-freeze The coolant performs as rust inhibitor and 1450 ml Coolant water pump lubricant as well as anti-freeze.
Page 85 BREAK-IN (RUNNING-IN) AND INSPECTION BEFORE RIDING MAXIMUM ENGINE SPEED RECOMMENDATION ................... 4-2 VARY THE ENGINE SPEED ........................4-2 BREAKING IN THE NEW TIRES ........................ 4-3 AVOID CONSTANT LOW SPEED ......................4-3 ALLOW THE ENGINE OIL TO CIRCULATE BEFORE RIDING ..............4-4 OBSERVE YOUR FIRST AND MOST CRITICAL SERVICE ..............
Page 86 This proper break-in is to achieving maximum life aids the mating process of the parts. It is and performance from your new Suzuki. The essential that some stress be placed on the following guidelines explain proper break-in engine components during break-in to procedures.
Page 87 BREAKING IN THE NEW TIRES AVOID CONSTANT LOW SPEED New tires need proper break-in to assure Operating the engine at constant low speed maximum performance, just as the engine (light load) can cause parts to glaze and not does. Wear in the tread surface by gradually seat in.
Page 88 ALLOW THE ENGINE OIL TO OBSERVE YOUR FIRST AND CIRCULATE BEFORE RIDING MOST CRITICAL SERVICE Allow sufficient idling time after warm or cold The initial service (1000 km maintenance) is engine start up before applying load or rev- the most important service your motorcycle ving the engine.
Page 89 INSPECTION BEFORE RIDING  WARNING  WARNING Using worn, improperly inflated, or incorrect tires will reduce stability and Failure to inspect and maintain your can cause an accident. motorcycle properly increases chance of an accident or equipment Follow all instructions in the TIRES sec- damage.
Page 90 Before riding the motorcycle, be sure to WHAT TO check the following items. Never underesti- CHECK FOR: CHECK mate the importance of these checks. Per- Steering • Smoothness form them before riding • No restriction of movement motorcycle. • No play or looseness Throttle •...
Page 91 Drive chain • Correct tension or slack • Adequate lubrication • No excessive wear or damage Tires • Correct pressure • Adequate tread depth • No cracks or cuts Engine oil Correct level Cooling • Proper coolant level system • No coolant leakage Lighting Operation of all lights and indicators...
Page 93 RIDING TIPS STARTING THE ENGINE ........................... 5-2 STARTING OFF ............................5-4 USING THE TRANSMISSION ........................5-6 RIDING ON HILLS ............................5-8 STOPPING AND PARKING ........................5-8 CARRYING A PASSENGER ........................5-11...
Page 94: Riding Tips
RIDING TIPS When the Engine is Cold: 1. Close the throttle completely and push the electric starter button. STARTING THE ENGINE 2. After the engine starts, let the engine run Before attempting to start the engine, make until the engine sufficiently warms up. sure: •...
Page 95  WARNING CAUTION Running the engine indoors or in a Running the engine too long without garage can be hazardous. Exhaust gas riding may cause the engine to overheat. contains carbon monoxide, a gas that is Overheating can result in damage to colorless and odorless and can cause internal engine components and discol- death or severe injury.
Page 96 STARTING OFF  WARNING  WARNING Removing your hands from the handle- bars or feet from the footrests during Riding this motorcycle at excessive operation can be hazardous. If you speed increases your chances of losing remove even one hand or foot from the control of the motorcycle.
Page 97 After moving the side stand to the fully up  WARNING position, squeeze the clutch lever and pause momentarily. Engage first gear by depress- Sudden side winds, which can occur ing the gear shift lever downward. Twist the when being passed by larger vehicles, at throttle grip toward you and at the same time tunnel exits or in hilly areas, can upset release the clutch lever gently and smoothly.
Page 98 USING THE TRANSMISSION Shifting up schedule The transmission is provided to keep the Gear position km/h miles/h engine operating smoothly in its normal → operating speed range. The gear ratios have been carefully chosen to meet the charac- → teristics of the engine. The rider should →...
Page 99  WARNING CAUTION Downshifting when engine speed is too Revving the engine into the red zone can high can: cause severe engine damage. • cause the rear wheel to skid and lose traction due to increased engine brak- Never allow the engine to rev into the red ing, resulting in an accident;...
Page 100 RIDING ON HILLS STOPPING AND PARKING • When climbing steep hills, the motorcy- 1. Twist the throttle grip away from yourself cle may begin to slow down and show to close the throttle completely. lack of power. At this point you should 2.
Page 101  WARNING  WARNING Inexperienced riders tend to underuti- Hard braking on wet, loose, rough, or lize the front brake. This can cause other slippery surfaces can cause wheel excessive stopping distance and lead to skid and loss of control. a collision.
Page 102 5. Park the motorcycle on a firm, flat sur- 6. Turn the ignition key to the “OFF” posi- face where it will not fall over. tion. 7. Turn the handlebars all the way to the  WARNING left and lock the steering for security. 8.
Page 103 CARRYING A PASSENGER WARNING Before you invite someone to be a passen- ger on your motorcycle, you need to be thor- The seat tail cover can be hot enough to oughly familiar with motorcycle operation. burn you and your passenger. The hot Adjust tire pressures...
Page 105 INSPECTION AND MAINTENANCE MAINTENANCE SCHEDULE ........................6-2 TOOLS ................................ 6-6 STEERING DAMPER MAINTENANCE ...................... 6-7 LUBRICATION POINTS ..........................6-8 BATTERY ..............................6-9 AIR CLEANER ............................6-11 SPARK PLUGS ............................6-21 FUEL HOSE .............................. 6-25 ENGINE OIL .............................. 6-26 ENGINE IDLE SPEED INSPECTION ....................... 6-34 THROTTLE CABLE PLAY ........................
Page 106: Inspection And Maintenance
If your motorcycle is used under in this owner’s manual. Ask your SUZUKI high stress conditions such as continuous dealer or a qualified mechanic to do the full throttle operation, or is operated in a...
Page 107 If you use your motorcycle under severe conditions, perform maintenance more often than shown in the chart. If you have any questions regarding maintenance intervals, consult your SUZUKI dealer or a qualified mechanic.
Page 108 MAINTENANCE CHART Interval: This interval should be judged by odometer reading or number of months, whichever comes first. Interval 1000 6000 12000 18000 24000 miles 4000 7500 11000 14500 Element months Air cleaner element – * Exhaust pipe bolts and muffler bolts –...
Page 109 1000 6000 12000 18000 24000 Interval miles 4000 7500 11000 14500 Element months – Clutch hose Replace every 4 years Drive chain Clean and lubricate every 1000 km (600 miles) * Brakes – Brake fluid *Replace every 2 years – Brake hose *Replace every 4 years Tires...
Page 110 TOOLS A tool kit is supplied and located inside the left frame cover.
Page 111 STEERING DAMPER NOTE: • Do not confuse the grease-like residue MAINTENANCE on the steering damper’s shaft with an oil 1. Keep the steering damper shaft 1 clean leak. Collection of this residue is normal at all times. and is from oil seal lubricant used in the 2.
Page 112 LUBRICATION POINTS Proper lubrication is important for smooth operation and long life of each working part of your motorcycle and also for safe riding. It is a good practice to lubricate the motorcy- cle after a long rough ride and after getting it wet it in the rain or after washing it.
Page 113  ..Motor oil BATTERY  ..Grease The battery is located under the front seat. Remove the front seat by referring to the 1..Clutch lever holder SEAT LOCK AND HELMET HOLDER sec- 2..Side stand pivot and tion. This battery is a sealed type battery spring hook and requires no maintenance.
Page 114  WARNING CAUTION Hydrogen gas produced by batteries can Reversing the battery lead wires can explode if exposed to flames or sparks. damage the charging system and the battery. Keep flames and sparks away from the battery. Never smoke when working near The red lead must go to the positive (+) the battery.
Page 115 AIR CLEANER CAUTION The air cleaner is located under the fuel tank. If the element has become clogged Clean or replace the air cleaner element with dust, intake resistance will increase frequently if the motorcycle is used in with a resultant decrease in power output dusty, wet or muddy conditions.
Page 116 REMOVAL 1. Place the motorcycle on the side stand. 2. Remove the front seat by referring to the SEAT LOCK AND HELMET HOLDER section. 4. Remove the screws and fasteners. Remove the right and left side frame covers, 2 by unhooking the side frame covers.
Page 117 6. Turn the ignition cover 4 clockwise and remove it. 7. Remove the bolts. Remove the fuel tank cap cover 5 with fuel tank upper cover 5. Remove bolts fasteners. Remove the right and left fuel tank cover 3 by unhooking the fuel tank covers. 6-13...
Page 118 8. Disconnect the couplers. NOTE: Drain the fuel from the fuel tank before tilting up the fuel tank if the fuel tank is full. 9. Remove the fasteners from both right and left side. 10. Remove the fuel tank fitting bolts 7. 6-14...
Page 119 11. To open the tool box, pull out the prop 12. Lift the front end of the fuel tank and stay 8. prop it up as shown above. Put the circle end of the prop stay onto the steering lock assembly. 6-15...
Page 120 13. Remove the fastener 9. 14. Loosen the right and left bolts 0. 6-16...
Page 121 15. Disconnect the coupler A. Pull out the 16. Pull out the tubes D, E. tube B. Disconnect the air cleaner sen- 17. Remove the air cleaner box. sor assembly C. 6-17...
Page 122 20. Remove the air cleaner element H. 18. Remove the 11 screws F. 19. Remove the cover G. 6-18...
Page 123 INSPECTION Inspect the air cleaner element condition. Remove the plug and drain water and oil at Replace the air cleaner element periodically. the periodic maintenance interval. The air cleaner drain plug is located beneath the air cleaner box. 6-19...
Page 124 INSTALLATION CAUTION Reinstall the cleaned element or new air cleaner element in reverse order of removal. Failure to position the air cleaner ele- Be absolutely sure that the element is ment properly can allow dirt to bypass securely in position and is sealing properly. the air cleaner element.
Page 125 SPARK PLUGS REMOVAL To remove the spark plugs, follow the proce- dure below: 1. Lift the fuel tank and remove the air cleaner box by referring to the AIR CLEANER section. 3. Pull off the ignition coils. CAUTION Improper removal of ignition coils can damage the ignition coils.
Page 126 SPARK PLUG INSPECTION 4. Remove the spark plugs with a spark plug wrench. Make sure that the 1.0 mm (0.04 in) wire- type feeler gauge does not insert between the spark plug gap A. If the gauge is CAUTION inserted into the gap, replace the plug with a new one.
Page 127 Use one of the spark plugs listed below or equivalent. Consult your Suzuki dealer or a qualified mechanic if you are not sure which spark plug is correct for your type of usage.
Page 128 INSTALLATION DENSO REMARKS If the standard plug is CAUTION CR8EIA-9 IU24D apt to get wet, replace with this plug. A crossthreaded or overtightened spark CR9EIA-9 IU27D Standard plug will damage the aluminum threads If the standard plug is of the cylinder head. CR10EIA-9 IU31D apt to overheat, replace...
Page 129 FUEL HOSE CAUTION Improper installation of ignition coils can damage the ignition coils. Install the ignition coils with your hand. Never hit the ignition coils with a tool. Reinstall the air cleaner box and fuel tank in the reverse order of removal. Inspect the fuel hose for damage and fuel leakage.
Page 130 ENGINE OIL Long engine life depends much on the selection of a quality oil and the periodic changing of the oil. Daily oil level checks and periodic changes are two of the most impor- tant maintenance items to be performed. ENGINE OIL LEVEL CHECK Follow the procedure below to inspect the engine oil level.
Page 131 ENGINE OIL AND FILTER CHANGE CAUTION Change the engine oil and oil filter at the ini- tial 1000 km (600 miles) and at each mainte- The engine oil level must be between the nance interval. The oil should be changed “L”...
Page 132  WARNING Engine oil and exhaust pipes can be hot enough to burn you. Wait until the oil drain plug and exhaust pipes are cool enough to touch with bare hands before draining oil. 3. Place a drain pan under the drain plug 4.
Page 133 • Wash with soap if oil contacts your skin. NOTE: Recycle or properly dispose of used oil. 5. Reinstall the drain plug and gasket. Tighten the plug securely with a wrench. Available from Suzuki dealer Oil filter wrench (Part No. 09915-40610) 6-29...
Page 134 7. Turn the oil filter 4 counterclockwise 8. Wipe off the mounting surface 5 on the and remove it with a Suzuki “cap type” oil engine where the new filter will be filter wrench or a “strap type” filter seated with a clean rag.
Page 135 Using an oil filter with the wrong design or thread specifications can cause oil leaks or engine damage. Use a genuine SUZUKI oil filter or an equivalent filter designed for your motor- cycle. 9. Smear a little engine oil around the rub- NOTE: To tighten the oil filter properly, it is ber gasket 6 of the new oil filter.
Page 136 11. Mark the top dead center position on the “cap type” filter wrench or on the oil filter. Mark top dead center Use an oil filter wrench to tighten the fil- Oil filter wrench ter 2 turns or to specified torque. Oil filter tightening torque: 20 N·m (2.0 kgf-m, 14.5 lb-ft) 12.
Page 137 NOTE: If you do not have a proper oil filter CAUTION wrench, have your Suzuki dealer perform this service. Engine damage may occur if you use oil that does not meet Suzuki’s specifica- tions. Use the oil specified in the FUEL, ENGINE OIL AND COOLANT RECOM- MENDATIONS section.
Page 138 1050 – 1250 r/min when the engine is warm. NOTE: If the engine idle speed is not within the specified range, ask your Suzuki dealer or a qualified mechanic to inspect and repair the motorcycle. 2.0 – 4.0 mm...
Page 139 To adjust the cable play: CLUTCH 1. Loosen the lock nut 1. 2. Turn the adjuster 2 so that the throttle grip has 2.0 – 4.0 mm (0.08 – 0.16 in) play. 3. Tighten the lock nut 1. LOWER  WARNING Inadequate throttle cable play can cause engine speed to rise suddenly when you turn the handlebar.
Page 140 If brake fluid gets quent loss of fluid, take your motorcycle in eyes, flush eyes with water and seek to a Suzuki dealer or a qualified medical attention. Wash thoroughly after mechanic for inspection. handling. Solution can be poisonous to animals.
Page 141 COOLANT CAUTION COOLANT LEVEL Spilled brake fluid can damage painted surfaces and plastic parts. Avoid spilling any fluid when filling the reservoir. Wipe up spills immediately. The coolant should be kept between the “F” (FULL) and the “L” (LOW) level lines in the reservoir tank at all times.
Page 142  WARNING Engine coolant is harmful or fatal if swal- lowed or inhaled. Do not drink antifreeze or coolant solu- tion. If swallowed, do not induce vomit- ing. Immediately contact a poison control center or a physician. Avoid inhaling mist or hot vapors; if inhaled, remove to fresh air.
Page 143 Suzuki dealer or a qualified mechanic if the drive chain needs to be replaced. The condition and adjustment of the drive chain should be checked each day before you ride.
Page 144 NOTE: The two sprockets should be problem if you know how. If necessary, con- inspected for wear when a new chain is sult your authorized Suzuki dealer or a qual- installed and replace them if necessary. ified mechanic. Damage to the drive chain means that the sprockets may also be damaged.
Page 145 Do not use a joint-clip type chain. Chain replacement requires a special riveting  WARNING tool and a high-quality, non-joint-clip type chain. Ask an authorized SUZUKI Kerosene can be hazardous. Kerosene is dealer or a qualified mechanic to per- flammable. Children or pets may be form this work.
Page 146  WARNING 2. After thoroughly washing the chain and Too much chain slack can cause the allowing it to dry, oil the links with Suzuki chain to come off the sprockets, result- ing in an accident or serious damage to chain lube or an equivalent chain lubri- cant.
Page 147 To adjust the drive chain, follow the proce- dure below:  WARNING A hot muffler can burn you. The muffler will be hot enough to burn you for some time after stopping the engine. Wait until the muffler cools to avoid burns.
Page 148 Rear axle nut tightening torque: 100 N·m (10.0 kgf-m, 72.5 lb-ft) NOTE: Do not adjust the drive chain beyond the adjustable range 4. Replace the drive chain before the drive chain exceeds the 20 – 30 mm limit. 4. Adjust the drive chain slack by turning the right and left chain adjuster bolts 3.
Page 149 BRAKES Inspect your brake system for the following items daily: This motorcycle utilizes front and rear disk • Inspect the fluid level in the reservoirs. brakes. Proper operation of brake systems • Inspect the front and rear brake system are vital to safe riding. Be sure to perform for signs of fluid leakage.
Page 150 BRAKE FLUID  WARNING Brake fluid is harmful or fatal if swal- lowed, and harmful if it comes in contact LOWER with skin or eyes. If swallowed, do not induce vomiting. Immediately contact a poison control center or a physician. If brake fluid gets in eyes, flush eyes with water and seek medical attention.
Page 151 Use only DOT4 brake fluid from a sealed container. Never use or mix differ- ent types of brake fluid. If there is fre- quent loss of fluid, take your motorcycle to a SUZUKI dealer or a qualified mechanic for inspection. 6-47...
Page 152 1. If a front or rear pad is worn to the grooved limit line REAR both front or both rear pads must be replaced with new ones by your authorized Suzuki dealer qualified service mechanic.
Page 153  WARNING Inspect brake pad wear before each use. Replacing only one or the two brake Ask your SUZUKI dealer or a qualified pads can result in uneven braking mechanic to replace brake pads if any action.
Page 154 REAR BRAKE PEDAL ADJUSTMENT CAUTION The rear brake pedal position must be prop- erly adjusted at all times or the disk brake An incorrectly adjusted brake pedal may pads will rub against the disk causing dam- force brake pads to rub against the disk age to the pads and to the disk surface.
Page 155 REAR BRAKE LIGHT SWITCH TIRES  WARNING Failure to follow these warnings may result in an accident due to tire failure. The tires on your motorcycle form the crucial link between your motorcycle and the road. Follow these instructions; • Check tire condition and pressure, and adjust pressure before each ride.
Page 156 TIRE PRESSURE AND LOADING  WARNING Proper tire pressure and proper tire loading are important factors. Overloading your tires Failure to perform break-in of the tires can lead to tire failure and loss of vehicle could cause tire slip and loss of control. control.
Page 157 Cold Tire Inflation Pressure TIRE CONDITION AND TYPE Proper tire condition and proper tire type affect vehicle performance. Cuts or cracks in LOAD SOLO RIDING DUAL RIDING the tires can lead to tire failure and loss of TIRE vehicle control. Worn tires are susceptible to 250 kPa 250 kPa puncture failures and subsequent loss of...
Page 158 If you use a different size or type of tire, • Ask your SUZUKI dealer or a qualified vehicle handling may be adversely affected, mechanic to perform tire repair, possibly resulting in loss of vehicle control.
Page 159  WARNING • Do not use an external repair plug to repair a puncture since the plug may work loose as a result of the Failure to follow these instructions about cornering forces experienced by a tubeless tires may result in an accident motorcycle tire.
Page 160 Have your motorcycle inspected by an authorized Suzuki dealer or a qualified ser- vice mechanic. Check the side stand/ignition interlock switch for proper operation as follows: 1.
Page 161 FRONT WHEEL REMOVAL  WARNING 1. Place the motorcycle on the side stand. If the side stand/ignition interlock sys- tem is not working properly, it is possi- ble to ride the motorcycle with the side stand in the down position. This may interfere with rider control during a left turn.
Page 162 3. Remove the bolt 2. 5. Loosen the axle holder bolts 4. 4. Loosen the axle holder bolts 3. 6. Place an accessory service stand or an equivalent stand under the swingarm to help stabilize the rear end. 7. Carefully position a jack under the exhaust pipe and raise until the front wheel is slightly off the ground.
Page 163 CAUTION Improper jacking may cause damage to the fairing or oil filter. Do not apply the jack head to the fairing lower part or the oil filter when jacking up the motorcycle. 9. Slide the front wheel forward. 10. Put the new wheel in place and insert the axle shaft.
Page 164 12. Hold the shaft and tighten the bolt 5 to 15. Tighten the axle holder bolts 7 to the the specified torque. specified torque. 13. Tighten the axle holder bolts 6 to the 16. Reinstall the brake calipers. specified torque. 17.
Page 165  WARNING  WARNING Failure to extend brake pads after install- Installing the front wheel in the reverse ing the wheel can cause poor braking direction can be hazardous. The tire for performance and may result in an acci- this motorcycle is directional. Therefore, dent.
Page 166 If you are not sure of the proper procedure, have your authorized Wait until the muffler cools to avoid SUZUKI dealer or a qualified mechanic burns. do this. Front axle tightening torque: 100 N·m (10.0 kgf-m, 72.5 lb-ft)
Page 167 1. Place the motorcycle on the side stand. 5. Draw out the axle shaft. 2. Remove the axle nut 1. 3. Place an accessory service stand or an equivalent stand under the swing arm to lift the rear wheel slightly off the ground. 4.
Page 168 6. With the wheel moved forward, remove 7. Pull the rear wheel assembly rearward. the chain from the sprocket. NOTE: Never depress the rear brake pedal with the rear wheel removed. It is very diffi- cult to force the pads back into the caliper assembly.
Page 169 If you are not sure of stroke and firm feel are restored. Also the proper procedure, have your check that the wheel rotates freely. authorized SUZUKI dealer or a quali- fied mechanic do this. Rear axle nut tightening torque: 100 N·m (10.0 kgf-m, 72.5 lb-ft)
Page 170 LIGHT BULB REPLACEMENT HEADLIGHT To replace the headlight bulb, perform the The wattage rating of each bulb is shown on following steps: the table below. When replacing a burned out bulb, always use the exact same wattage rating. Using other than the specified rating can result in overloading the electrical sys- tem or premature failure of a bulb.
Page 171 3. Unhook the bulb holder spring 4 and 2. Pull up the rubber cover. Disconnect the socket 2 from the headlight and remove pull out the bulb 5. the rubber cap 3. CAUTION Oil from your skin may damage the head- light bulb or shorten its life.
Page 172 Headlight Beam Adjustment Position Light The headlight beam can be adjusted both 1. Tilt up the instrument panel by referring vertically and horizontally if necessary. Pull to the Headlight section. up the rubber cover to adjust the headlight beam. 2. Remove the fasteners. Remove the headlight upper cover 1 by unhooking To adjust the beam vertically: the headlight upper cover.
Page 173 4. Pull out the socket 3. 3. Remove the screws. Remove the head- light lower cover 2 by unhooking the 5. Pull off the bulb from the socket. headlight lower cover. 6-69...
Page 174 FRONT TURN SIGNAL LIGHT To replace the turn signal light bulb, follow these directions. 1. Remove the fuel tank covers by referring to the AIR CLEANER section. 3. Push in on the bulb, turn it to the left, and pull it out. 4.
Page 175 REAR TURN SIGNAL LIGHT CAUTION To replace the turn signal light bulb, follow these directions. Overtightening the screws when rein- stalling the lens may cause the lens to crack. Tighten the screws only until they are snug. 1. Remove the screw 1. 6-71...
Page 176 2. Pull out the lens. Remove the screw 2. 3. Push in on the bulb, turn it to the left, and pull it out. 4. To fit the replacement bulb, push it in and twist it to the right while pushing. 6-72...
Page 177 LICENSE PLATE LIGHT CAUTION To replace the license plate light bulb, follow the procedure steps: Overtightening the screws when rein- stalling the lens may cause the lens to crack. Tighten the lens screws only until they are snug. 1. Remove the bolts and screws. Remove the rear fender cover 1.
Page 178 2. Remove the nuts 2. 3. Remove the screws 3 and take off the lens 4. 6-74...
Page 179 CAUTION Overtightening the screws when rein- stalling the lens may cause the lens to crack. Tighten the screws only until they are snug. 4. Push in on the bulb, twisting it to the left, and pull it out. 5. To fit the replacement bulb, push it in and twist it to the right while pushing.
Page 180 FUSES The main fuse is located under the center lid. To access the fuse, remove the seat by referring to the SEAT LOCK AND HELMET HOLDER section. Remove the fasteners. Remove the center lid. One 30A spare fuse is located inside the fuse box cover.
Page 181 If the new tion. Three spare fuses (one 15A and two fuse blows in a short time, consult your 10A) are provided inside the fuse box. Suzuki dealer or a qualified mechanic immediately. 6-77...
Page 182 FUSE LIST • 30A MAIN fuse protects all electrical cir- cuits. • 10A HEAD-HI fuse protects the head- light high beam and speedometer. • 10A HEAD-LO fuse protects the head- light low beam. • 10A IGNITION fuse protects the cooling fan relay, ignition coils, starter relay, fuel pump relay, solenoid, ECU, oxygen sen- sor, side stand relay and *Immobilizer.
Page 183 TROUBLESHOOTING FUEL SUPPLY CHECK ..........................7-2 IGNITION SYSTEM CHECK ........................7-3 ENGINE STALLING ............................ 7-4...
Page 184: Troubleshooting
Such damage may not be covered under warranty. If you are not sure about the proper action, consult your Suzuki dealer or a qualified mechanic about the problem. If the engine refuses to start, perform the fol- lowing inspections to determine the cause.
Page 185 3. If there is no spark, clean the spark plug. Replace it if necessary. Retry the above procedure with the cleaned spark plug or new one. 4. If there is still no spark, consult your Suzuki dealer for repairs.
Page 186 Suzuki dealer. Refer to the Avoid performing this check if you are “INSTRUMENT PANEL” section for an not familiar with this procedure, or if you...
Page 187 MOTORCYCLE CLEANING AND STORAGE PROCEDURE MOTORCYCLE CLEANING ........................8-2 STORAGE PROCEDURE ........................... 8-5 PROCEDURE DURING STORAGE ......................8-7 PROCEDURE FOR RETURNING TO SERVICE ..................8-7...
Page 188 MOTORCYCLE CLEANING AND CAUTION STORAGE PROCEDURE Radiator fins can be damaged by spray- MOTORCYCLE CLEANING ing high pressure water on them. Washing the Motorcycle Do not spray high pressure water on the When washing the motorcycle, follow the radiator fins. instruction below: 1.
Page 189 5. Check carefully for damage to painted CAUTION surfaces. If there is any damage, obtain “touch-up” paint and “touch-up” the dam- High pressure washers and parts age following the procedure below: cleaner can damage your motorcycle. a. Clean all damaged spots and allow them to dry.
Page 190 Waxing the Motorcycle Inspection after Cleaning After washing the motorcycle, waxing and For extended life of your motorcycle, lubri- polishing are recommended to further pro- cate according to “LUBRICATION POINTS” tect and beautify the paint. section. • Only use waxes and polishes of good ...
Page 191 For this reason, the stabilized gasoline fills the fuel injec- Suzuki recommends that you trust this tion system. maintenance work to your Suzuki dealer. If you need to service the machine for storage ENGINE yourself, follow the general guidelines below.
Page 192 BATTERY EXTERNAL 1. Remove the battery from the motorcycle. • Spray all vinyl and rubber parts with rub- ber preservative. NOTE: Be sure to remove the negative ter- • Spray the unpainted surfaces with rust minal first, then remove the positive termi- preventative.
Page 193 PROCEDURE DURING STORAGE PROCEDURE FOR RETURNING TO Once a month, recharge the battery with a SERVICE specified charging rate (Ampere). Standard • Clean the entire motorcycle. charging rate is 1.2A × 5 to 10 hours. • Reinstall the battery. NOTE: Be sure to connect the positive ter- minal first, then connect the negative termi- nal.
Page 194: Specifications
SPECIFICATIONS DIMENSIONS AND DRY MASS Overall length ............... 2220 mm (87.4 in) 2245 mm (88.4 in) ... Canada Overall width................. 800 mm (31.5 in) Overall height ............... 1085 mm (42.7 in) Wheelbase ................1525 mm (60.0 in) Ground clearance..............120 mm (4.7 in) Seat height ................
Page 195 DRIVE TRAIN Clutch ................... Wet multi-plate type Transmission ................ 6-speed constant mesh Gearshift pattern ..............1-down, 5-up Primary reduction ratio ............1.596 (83/52) Gear ratios, Low..............2.615 (34/13) 2nd ..............1.937 (31/16) 3rd ..............1.526 (29/19) 4th ..............1.285 (27/21) 5th ..............
Page 196 ELECTRICAL Ignition type ................Electronic ignition (Transistorized) Spark plug ................NGK CR9EIA-9 or DENSO IU27D Battery.................. 12V 36.0 kC(10 Ah)/10 HR Generator ................Three-phase A.C. generator Main fuse................30A Fuse ..................15/15/10/10/10/10/10A Headlight ................12V 60/55W (H4) Turn signal light ..............12V 21W License plate light..............
Page 198 INDEX ACCESSORY USE AND ENGINE IDLE SPEED INSPECTION..6-34 MOTORCYCLE LOADING ......1-2 ENGINE OIL ........3-4 6-26 AIR CLEANER..........6-11 ENGINE STALLING ........7-4 ALLOW THE ENGINE OIL TO CIRCULATE BEFORE RIDING ........4-4 AVOID CONSTANT LOW SPEED .....4-3 FRONT WHEEL REMOVAL..... 6-57 FUEL ............
Page 199 KEY (Canada)..........2-5 OBSERVE YOUR FIRST AND KEY (EU and Australia) ......2-6 MOST CRITICAL SERVICE ....... 4-4 LEFT HANDLEBAR ........2-34 PROCEDURE DURING STORAGE... 8-7 LIGHT BULB REPLACEMENT....6-66 PROCEDURE FOR RETURNING TO LOCATION OF PARTS ......2-2 SERVICE............ 8-7 LUBRICATION POINTS ......6-8 LUGGAGE STRAPS.........2-50 REAR BRAKE PEDAL......
Page 200 USING THE TRANSMISSION....5-6 SIDE STAND/IGNITION INTERLOCK SWITCH............6-56 SPARK PLUGS ........6-21 VARY THE ENGINE SPEED...... 4-2 STARTING OFF .........5-4 STARTING THE ENGINE......5-2 STEERING DAMPER MAINTENANCE..........6-7 STOPPING AND PARKING .......5-8 STORAGE PROCEDURE ......8-5 SUSPENSION ADJUSTMENT ....2-52 SUZUKI DRIVE MODE SELECTOR ..2-32 Total page: 200...
Page 203 300 TAKATSUKA, MINAMI, HAMAMATSU, JAPAN Printed in Japan...

Suzuki GSX1300BK Owner's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Suzuki GSX1300BK

Summary of Contents for Suzuki GSX1300BK

Page 9: Consumer Information

Page 26: On Position

Page 94: Riding Tips

Page 106: Inspection And Maintenance

Page 184: Troubleshooting

Page 194: Specifications

Table of Contents
