[Reference] APPENDIX D – INTERNAL CHARACTER TABLES, APPENDIX F - FONT LOADER
SOFTWARE.
ESC { n
[Name] Inverse printing mode
[Format] ASCII
Hex
Decimal
<00>H ≤ n ≤ <FF>H
[Range]
[Description] Turns inverse printing mode on/off.
When the LSB of n is 0, Inverse printing mode off.
When the LSB of n is 1, Inverse printing mode on.
A B C D
1 2 3 4 5
[Notes] Each character is printed upside down (180º rotating) and the sequence of
●
characters is printed backwards as well. The character sent fist is printed al the right
margin and subsequent characters are printed from right to left. The characters lines
transmission order changes from the normal mode, because the first line is sent to
the printer must be the last to appear on the ticket, and the last line is sent must be
the first to appear on the ticket.
When inverse mode is setting, the rotated mode (90º) is disabled.
●
This command is enabled only when processed at the beginning of a line.
●
[Default] n = <00>H
GS ! n
[Name] Select character size
[Format] ASCII
Hex
Decimal
<00>H ≤ n ≤ <77>H. While n ≤ <7X>H and n ≤ <X7>H
[Range]
[Description] Selects the character height using bits 0 to 3 and selects the character width using bits
4 to 7, as follows:
ESC {
1B 7B
27 123 n
Inverse printing
mode OFF
GS !
1D 21
29 33
n
(in hex)
x 1 x 2
x 1 00 10
x 2 01 11
EPC1800 SERIES OPERATION MANUAL
n
n
Paper
feed
direction
n
n
n
Horizontal size (WIDTH)
x 3 x 4 x 5 x 6
20 30 40 50
21 31 41 51
Inverse printing
mode ON
x 7 x 8
60 70
61 71
