Fenix EPC1800 Operation Manual page 22

LF
[Name] Print and line feed
[Format] ASCII
Hex
Decimal
[Description] Prints the data in the print buffer and feeds one line, based on the current line spacing.
[Note] This command sets the print position to the beginning of the line.
[Reference] ESC 2, ESC 3.
CR
[Name] Print and carriage return
[Format] ASCII
Hex
Decimal
[Description] When automatic line feed is enabled, this command operates the same as LF; when
automatic line feed is disabled, this command is ignored.
[Notes] This command is effective only by means of programming buttons (see section 5.6.2-
●
Programming mode).
Sets the print starting position to the beginning of the line.
●
[Reference] LF
DLE EOT n
[Name] Real-time status transmission
[Format] ASCII
Hex
Decimal
<01>H ≤ n ≤ <04>H
[Range]
[Description] Transmits the selected printer status specified by n in real-time, according to the
following parameters:
The status is transmitted whenever the data sequence <10>H<04>H<n> (<01>H ≤ n
[Notes]
●
≤ <05>H) is received.
The printer transmits the current status. Each status item is represented by one byte.
●
The printer transmits the status without confirming whether the host computer can
●
receive data (in serial interface).
The printer executes this command upon receiving it.
●
This command is executed even when the printer is offline, the receiver buffer is full,
●
or there is an error status with a serial interface model.
n = <01>H: Printer status
Bit OFF/ON Function
0
1
2
3
4
5
LF
0A
10
CR
0D
13
DLE EOT
10 04
16 4
n = <01>H: Transmit printer status
n = <02>H: Transmit offline status
n = <03>H: Transmit error status
n = <04>H: Continuous paper sensor status
n = <05>H: Paper sensor status
OFF Not used. Fixed to OFF
ON Not used. Fixed to ON
OFF Not used. Fixed to OFF
OFF Online
ON Offline
ON Not used. Fixed to ON
OFF Does not wait for online error recovery
ON Waits for online error recovery
EPC1800 SERIES OPERATION MANUAL
n
n
n
22 of 53
