<00>H / <30>H
<01>H / <31>H
When enabling the automatic status report, the printer remains in this state
indefinitely, until it becomes disabling, or until switch the power off.
After enabling the automatic status report, the printer returns the 5 states mentioned
in the command DLE EOT n, every 0.5 seconds in the following order:
First status sent ........................................ Last status sent
(status1) ..................................... ........... (status5)
[Default]
n = <30>H
[Reference]
DEL EOT
GS f n
[Name]
Select font for Human Readable Interpretation (HRI) characters
[Format]
ASCII
Hex
Decimal
<00>H ≤ n ≤ <01>H, <30>H ≤ n ≤ <31>H
[Range]
[Description]
Selects a font for the HRI characters used when printing a bar code.
n selects a font from the following table:
<00>H / <30>H
<01>H / <31>H
[Notes]
HRI indicates Human Readable Interpretation.
HRI characters are printed at the position specified by GS H.
HRI characters are always printed at X-Scale = 1 and Y-Scale = 1
[Default]
n = <01>H
[Reference]
GS H, GS k
GS h n
[Name]
Select bar code height
[Format]
ASCII
Hex
Decimal
<01>H ≤ n ≤ <FF>H
[Range]
[Description]
Selects the height of the bar code.
n specifies the number of dots in the vertical direction (n x 0.125mm).
[Default]
n = <A2>H (162 dots20,25mm)
[Reference]
GS k
GS k m n d1...dn
[Name]
Print bar code
[Format]
ASCII GS
Hex
Decimal
[Range]
m = <43>H, m = <45>H, m = <46>H or m = <49>H
(n and d depend on the bar code system used).
[Description]
Selects a bar code system and prints the bar code.
n
Disable automatic status report
Enable automatic status report
status1 = Transmit printer status
status2 = Transmit offline status
status3 = Transmit error status
status4 = Continuous paper sensor status
status5 = Paper sensor status
GS
f
1D
66
29
102
n
Font
Font A (12x24)
Font B (8x16)
GS
h
1D
68
29
104
k
m
1D
6B
m
29
107
EPC1800 SERIES OPERATION MANUAL
Function
n
n
n
n
n
n
n
d1...dn
n
d1...dn
m
n
d1...dn
36 of 53
