Fenix EPC1800 Operation Manual page 30

ESC c 5 n
[Name] Enable/disable the on-board button
[Format] ASCII
Hex
Decimal
<00>H ≤ n ≤ <FF>H
[Range]
[Description] Enables or disables the on-board button.
When the LSB of n is 0, the on-board button is enabled.
When the LSB of n is 1, the on-board button is disabled.
[Notes] Only the lowest bit of n is valid.
[Default] n = <00>H
ESC d n
[Name] Print and feed n lines
[Format] ASCII
Hex
Decimal
<00>H ≤ n ≤ <FF>H
[Range]
[Description] Prints the data in the print buffer and feeds n character lines.
[Notes] This command sets the print starting position to the beginning of the line.
●
This command does not affect the line spacing set by ESC 2 or ESC 3.
●
The maximum paper feed amount is 1016 mm {40"}. If the paper feed amount (n x
●
line spacing) of more than 1016 mm {40"} is specified, the printer feeds the paper
only 1016 mm {40"}.
Every line feed corresponds to the current selected font height (24 dots for Font A
●
and 16 dots for Font B).
[Reference] ESC 2, ESC 3.
ESC j n
[Name] Back feed paper
[Format] ASCII
Hex
Decimal
<00>H ≤ n ≤ <FF>H
[Range]
[Description] Back feeds the paper [n x 0.0625 mm (0.0024")].
[Notes] This command is only effective when the optical mark sensor is enabled.
●
Allows readjust the paper position when the black mark has surpassed the black
●
mark sensor, and it is needed back feed paper to prepare the cutting.
ESC t n
[Name] Select character code font
[Format] ASCII
Hex
Decimal
<00>H ≤ n ≤ <03>H, <30>H ≤ n ≤ <33>H
[Range]
[Description] Selects the character fonts between the internal character fonts and the Windows
loaded character fonts.
n
<00>H / <30>H
<01>H / <31>H
<02>H / <32>H
<03>H / <33>H
[Default] n = <30>H
ESC c 5
1B 63 35
27 99 53
ESC d
1B 64
27 100
ESC j
1B 6A
27 106
ESC t
1B 74
27 116
Character font selected
Both internal font A and font B are selected.
External loaded font A is selected.
Internal font B is selected.
External loaded font B is selected.
Internal font A is selected.
Both external loaded font A and font B are selected.
EPC1800 SERIES OPERATION MANUAL
n
n
n
n
n
n
n
n
n
n
n
n
30 of 53
