Fig. 16 - Logo Loading - Fenix EPC1800 Operation Manual

FS DC2 ESC
[Name] Serial number transmission
[Format] ASCII
Hex
Decimal
[Description] Transmits the interface exclusive serial number. This number consists of 12
hexadecimal digits (6 bytes). Transmission order is from least to most significant byte.
Example: Serial number = 12D4AC78F38E
First byte sent ........................................Last byte sent
8E ................. F3 78 AC D4 .............12
[Notes] The interface exclusive serial number can be used to assure absolute traceability
●
because no two parts are alike.
The serial number can also be verified by printing the self-test:
●
* RECORDS *
Serial num.
On/Off times:
Meters:
Time ON(H:M):
FS GS ESC n
[Name] Historic counters transmission
[Format] ASCII
Hex
Decimal
n
<31>H On/off times Number of times the printer has been turned on
<32>H Time On
<33>H Meters
<34>H Cuts
<31>H ≤ n ≤ <34>H
[Range]

Fig. 16 - Logo loading

FS DC2
1C 12
28 18 27
0FE057057142
100
100
0:10
FS GS ESC
1C 1D 1B
28 29 27
Type of
counter
Number of seconds the printer has been working
Number of meters the printer has printed
Number of cuts performed
EPC1800 SERIES OPERATION MANUAL
ESC
1B
n
n
n
Description
(Hex)
Bytes
returned
2
4
2
2
