NOTE: If EPC1800 detects no paper or platen open while is printing it will stop the
communication in order not loose any data.
5.5- LED INDICATOR
EPC1800 has one indicator led to visually inform about the printer status. When the LED lights or
blink GREEN means normal operation. The LED blinks ORANGE whether the EPC1800 has detect a
non-recoverable error. The LED blinks RED when a recoverable error has been occurred. If the lights
RED, there is no paper or the door has been opened. See section 5.7- ERROR PROCESSING
5.6- SPECIAL PRINTING MODES
Besides the normal printing mode in which all the received data are printed according to the
settings or conditions fixed by the commands, the EPC1800 printer allows three special working modes:
self-test mode, programming mode and the hexadecimal mode.
5.6.1- Self-test mode
The printer provides the self-
test
mode
with
functionality: showing information
of the settings of that particular
printer model and verifying the
printing.
To enter the self-test mode,
the printer must be powered on
while keeping pressing the button.
The
EPC1800
printing a report, which allows
checking
the
features
particular model, like the firmware
current version, control functions of
the communications protocol, and
so on.
If, once this printing has been
finished, the button is kept pressed;
the
printer
will
start
continuously
and
repetitively
character
map
until
concludes the self-test by printing '*
* completed * *'.
option of the self-test mode has the
goal of validating the printing speed
and quality.
At the end of the self-test
page there are few lines showing
the three different maintenance
counts:
1- Times that the printer has been
switched on.
2- Time (in half hours) that the printer has been powered on.
3- Meters of paper printed.
two
different
will
start
of
this
printing
a
it
finally
This second
EPC1800 SERIES OPERATION MANUAL
FENIX IMVICO
EPC1800 V1.0.1
SERIAL PORT SETTINGS
Data bits:
8 (fixed)
Stop bits:
1 (fixed)
Baud rate:
115200 bauds
Parity bit:
No parity
Protocol:
Hard.RTS/CTS
USB PORT SETTINGS
USB V2.0
480Mbits/s
DEFAULT TEXT SETTINGS
Set character
EUROPE 437
Table A (12x24 dots)
Character Height:
Character Width:
Character space:
Line space:
Print density:
Standard
Carry Return:
Disabled
EXTERNAL TABLES:
(No table loaded)
LOGOS LOADED:
(No logo loaded)
* RECORDS *
Serial num.
0FE057057142
On/Off times:
Meters:
Time ON(H:M):
!"#$%&'()*+,-./01234567
!"#$%&'()*+,-./012345678
"#$%&'()*+,-./0123456789
#$%&'()*+,-./012345679 :
$%&'()*+,- ./012345679 : ;
%&'()*+,-./0123456779 : ; <
&'()*+,-./0123456779 : ; < -
'()*+,-./0123456779 : ; < - >
()*+,-./0123456779 : ; < - >?
)*+,-./0123456779 :;< - >?@
*+,-./0123456779 :;< - >?@A
+,-./0123456779 :;< - >?@AB
,-./0123456779 :;< - >?@ABC
.
.
.
.
.
1
1
4
vwxyz{ | }~ !"#$%&'()*+,
15
wxyz{ | }~ !"#$%&'()*+,-
xyz{ | }~
!"#$%&'()*+,-.
yz{ | }~
!"#$%&'()*+,-./
z{ | }~
!"#$%&'()*+,-./0
{ | }~
!"#$&'()*+ , - . /01
| }~
!"#$&'()*+ , - . /012
* * completed * *
100
100
0:10
Fig. 11 - SELF-TEST
mode example
16 of 53
