6.3- DESCRIPTION OF THE CONTROL COMMANDS
Command
Name
LF
Print and line feed
CR
Print and carriage return
DLE EOT
Real-time status transmission
DC3 ESC FS GS
Program printer settings
ESC SP
Set right-side character spacing
ESC DC2 GS BEL Save current settings into non-volatile memory
ESC DC3 GS BS
Save default settings
ESC !
Select print mode(s)
ESC –
Turn underline mode on/off
ESC 2
Select default line spacing
ESC 3
Set line spacing
ESC @
Initialize printer
ESC E
Turn emphasized mode on/off
ESC G
Turn double-strike mode on/off
ESC I
Turn reverse mode on/off
ESC J
Print and feed paper
ESC M
Select character font
ESC V
Character rotation
ESC a
Select justification
ESC c 5
Enable/disable panel buttons
ESC d
Print and feed n lines
ESC j
Back feed paper
ESC t
Select character code table
ESC {
Inverse print mode on/off
GS !
Select character size
GS ( A
Execute test print
GS ( C
Erase all logos
GS B
Turn white/black reverse printing mode on/off
GS E
Set printing speed
GS H
Select printing position of HRI characters
GS I
Firmware version query
GS L
Set left margin
GS P
Print a 2D AZTEC format barcode
GS Q
Print a 2D QR format barcode
GS T
Set print position to the beginning of print line
GS a
Automatic status report
GS f
Select font for HRI characters
GS h
Set bar code height
GS k
Print bar code
GS v 0
Print raster bit image
GS w
Set bar code width
FS p
Print NV bit image
FS q
Define NV bit image
FS DC2 ESC
Serial number query
FS GS ESC
Historic counter transmission
Table 1. - Command List
EPC1800 SERIES OPERATION MANUAL
Command
classification
Executing
Setting
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
Page
22
22
22
X
24
X
25
X
26
X
26
X
26
X
27
X
27
X
27
X
27
X
27
X
28
X
28
28
X
28
X
29
29
X
30
30
30
X
30
31
X
31
32
32
X
33
X
33
X
33
34
X
34
34
35
35
35
X
36
X
36
36
38
X
39
39
X
40
41
41
21 of 53
