Fig. 3 - Power Consumption Vs Input Voltage - Fenix EPC1800 Operation Manual

*Paper Feed and Stand-by parameters are shown multiplied by 10.
Fig. 3 - Power consumption vs input voltage (12-24VDC version)
3.7- BARCODE SPECIFICATIONS
Standard barcodes
2D barcodes
3.8- MECHANICAL SPECIFICATIONS
Overall dimensions (W x D x H)
Weight (without paper)
3.9- ENVIRONMENTAL CONDITIONS
Operating temperature
Storage temperature
Life span (at 25ºC )
Activation pulse resistance
Abrasion resistance
EAN-13, CODE39, ITF, CODE128
QR, AZTEC
89.2 x 65.6 x 89.4mm
130g
-20 to 70ºC
-30 to 80ºC (without paper, in a dry place)
100 millions pulses or more (print ratio=12'5%).
50 Km or more
EPC1800 SERIES OPERATION MANUAL
9 of 53
