Get to Know Your Saw

The major components of your saw are identified below. Make sure you can identify these components in order
to follow the instructions in this manual.
2
5
14
17
18
12
10
9
14 SawStop 10" Industrial Cabinet Saw
Cabinet Saw Manual 1st Reprint.i14 14
1
4
6
Fig. 2
3
19
Fig. 3
2
16
External Components
1.
2.
3.
4.
5.
6.
8
7.
8.
9.
10.
11.
11
12.
13.
14.
15.
15
16.
17.
18.
19.
7
13
Table Top
Extension Wings
Blade Guard
Standard Table Insert
Switch Box
Elevation Hand Wheel
Tilt Hand Wheel
Motor Cover
Terminal Box
Dust Port
Miter Gauge
Blade Wrenches (2)
Belt Access Door
Bypass Key
Spreader / Riving Knife
Storage Pin
Miter Gauge Slots
Tilt Angle Indicator (red)
Tilt Angle Scale
Disconnect Switch
