Cabinet and Table Assembly Parts List

No.
1
2
N/A
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
Cabinet Saw Manual 1st Reprint.i81 81
Description
Table
Rear Lock Down Screw for Insert
Extension Wing Assembly (complete)
Cast Iron Wing
M10x1.5x30 Hex Head Bolt
M10.2x18.5 Lock Washers
M10x25x3 Washers
M10x1.5x25 Socket Head Set Screw
Standard Insert Assembly (complete)
Rear Leveling Screw
M6x1x14 Front Leveling Screw
Threading Insert
M5x0.8x20 Front Lock Down Screw
M6x1x8 Set Screw
Cabinet
Surge Suppressor: 200V - 240V
Surge Suppressor: 415V - 480V
Strain Relief Coupling
Belt Access Door
Belt Access Door Latch
Belt Access Door Latch Screw
Grommet for Cable Aperture
Cover Plate for Tilt Rod Aperture
M6x1.0x16 Phillips Head Screw
Blade Wrench
Wrench Bracket
M8x1.25x10 Socket Head Bolt
M8.2x15.4 Lock Washer
Grommet for Terminal Box
Terminal Block
M5x0.8x20 Phillips Head Screw
Equipment Ground Screw
Terminal Box Cover
3/16-24NCx1.4 Terminal Cover Screw
M10x1.5x30 Hex Head Bolt
M10.2 x 18.5 Lock Washer
M10x25x3 Washer
Part No. Qty.
CB104 001 1
CB104 002 2
CB104 003 2
CB104 004 2
CB104 005 6
CB104 006 6
CB104 007 6
CB104 008 2
CB104 009 1
CB104 010 2
CB104 011 2
CB104 012 1
CB104 013 1
CB104 014 2
CB104 015 1
CB104 276
1
CB104 277
CB104 017 1
CB104 018 1
CB104 019 1
CB104 020 4
CB104 021 1
CB104 022 1
CB104 023 2
CB104 024 2
CB104 025 1
CB104 026 1
CB104 027 1
CB104 028 1
CB104 029 1
CB104 030 2
CB104 031 1
CB104 032 1
CB104 033 1
CB104 034 8
CB104 035 9
CB104 036 8
