- Page 1 SawStop ® T-Glide Fence System- ™ Industrial Series II OWNER’S MANUAL...
-
Page 2: Warranty
This warranty is void if the fence system or any portion of the fence system is modified without the prior written permission of SawStop, LLC, or if the fence system is located or has been used outside of the country where the authorized SawStop distributor from whom the fence system was purchased resides. - Page 3 While unpacking your saw, verify that you have all the components shown below for your specific fence system. The T-Glide Fence System – Industrial Series II is available in either a 52” system or a 36” system. Although the components pictured below are from the 52” system, the components from the 36” system are similar.
- Page 4 Installation To install the rails, extension table, and fence you will need the following tools: 5 mm hex driver and 6 mm hex key (included) 13 mm and 17 mm wrenches (or adjustable wrench) Phillips head screwdriver Installing the Front Rail: The first step in installing the fence is to attach the front rail to the table. Please see pages 14 and 16 for exploded views of the rails and extension tables.
- Page 5 Installing the Rear Rail: You install the rear rail like you installed the front rail, except that you will probably want to leave the rear rail a little loose until you get the extension table installed. The rear rail is attached to the main table by two M8 x 25 (6) countersunk socket head bolts, as shown by the arrows in Fig.
- Page 6 Locate the two leg support brackets. Remove the two M8 x 20 countersunk socket head bolts (21) from the hardware bag along with two M8 washers (14), two M8 lock washers (15) and two M8 hex nuts (16). Mount one leg support bracket to the underside of each of the rails as shown in Fig.
- Page 7 The extension table mounts to the rails with bolts that pass through holes in the rails and extension table. If you have an extension table for a 36” fence system, take two M8 x 40 countersunk socket head bolts (17) and insert one through the hole in the front rail closest to the saw and the other through the hole in the rear rail closest to the saw, as shown in Fig.
- Page 8 Attach each support leg to the corresponding leg support bracket with an M10 x 40 hex head bolt (23), two M10 washers (24), and an M10 lock nut (25), as shown in Fig. 9, and fully tighten the bolts using two 17 mm wrenches. Note that the leg support brackets align with different holes in the front and rear legs because the brackets are at different elevations.
- Page 9 Next, install the M8 x 45 socket head bolt (26) and D-washer (27) through the hole in the center of the left side of the extension table. The bolt should also extend through the center hole in the right extension wing. Make sure the flat edge of the D-washer is facing upward.
- Page 10 Installing the Main Tube: The main tube is installed on the front rail using the M8 x 16 hex head bolts with attached washers (7). Position the tube on the horizontal portion of the front rail with the rulers facing up and the 12”...
- Page 11 Next, attach the fence handle to the fence by threading the handle into the cam lock. Press down on the fence handle to clamp the fence to the main tube. If the fence does not clamp tightly enough to the main tube to hold its position against a moderate amount of force, you can increase the clamping force by turning both parallelism adjustment screws clockwise.
- Page 12 Fence Adjustments: Although the fence is factory-adjusted to nominal settings, it is usually necessary to make final adjustments once your rails and extension table have been installed on the saw. The first step is to align the face plates to be parallel to the miter slots. Begin by sliding the fence along the tube until the left face plate is flush with the right edge of the right miter slot.
- Page 13 Place a combination square on the table top and against the left face plate. See Fig. 18. Use a 6 mm hex key to adjust the leveling screws as necessary until the face plate is parallel to the vertical edge of the combination square.
- Page 14 It is usually possible to adjust the position of the face plates by lightly tapping the top or bottom edge of the face plates with a plastic or wooden mallet. However, if the face plates do not move when tapped, you can loosen the mounting screws as described below to adjust the face plates.
- Page 15 This page is blank. page 13...
- Page 16 page 14...
-
Page 17: Fence Assembly
Fence Assembly Description Part No. Qty. Fence Assembly (items 1 - 18 assembled)* TGI2-FA Fence Tube TGI2-001 Face Plate TGI2-002 M6 x 1 x 12 Socket Head Screw TGI2-003 Handle TGI2-004 Cam Lock TGI2-005 M10 x 1.5 x 50 Hex Head Bolt TGI2-006 M10 x 1.5 Lock Nut TGI2-007... - Page 18 page marker page 16...
- Page 19 36” Rails and Extension Table Parts List Description Part No. Qty. 36” Rail Assembly (hardware in fence box)* TGI2-R36A 36” Front Rail TGI2-025 M8 x 1.25 x 35mm Flat Head Socket Screw TGI2-026 M8 x 23 x 2 Washer TGI2-027 M8 Lock Washer TGI2-028 M8 x 1.25 Hex Nut...
- Page 20 page marker page 18...
- Page 21 52” Rails and Extension Table Parts List Description Part No. Qty. 52” Rail Assembly (hardware in fence box) TGI2-R52A 52” Front Rail TGI2-060 M8 x 1.25 x 35mm Flat Head Socket Screw TGI2-026 M8 x 23 x 2 Washer TGI2-027 M8 Lock Washer TGI2-028 M8 x 1.25 Hex Nut...
- Page 22 Service - (503) 582-9934 Fax - (503) 570-3303 Email: info@sawstop.com Updates of this manual may be available at www.sawstop.com. Copyright SawStop, LLC. All Rights Reserved. SawStop is a registered trademark and T-Glide is a trademark of SawStop, LLC. May 2017...
