Chapter 2 - Installation
Installation (Mechanical)
Locating the unit in the operating position
The UPS cabinets are fitted with castors on the base to allow ease of movement and positioning. When
the equipment has been finally positioned ensure the adjustable feet are set so that the UPS will remain
stationary and stable
Ensure the following considerations are observed when locating the equipment:
Clearances
Cooling air enters the module through ventilation grills located at the bottom of the cabinet and is ex
hausted through the fan grills located on the front panel; you must therefore allow for a minimum gap
of 170 mm behind the unit to allow adequate air flow. Clearance around the front of the equipment
should be sufficient to enable free passage of personnel with the door fully opened.

Raised floor installation

If the equipment is to be located on a raised floor it must be mounted on a pedestal suitably designed
to accept the equipment point loading.
Refer to the base view to design this pedestal.
Cable entry
Cables enter the UPS cabinet from the rear.
UPS Mechanical Characteristics
Height
Width
Depth
Weight:
Hinet cabinet
with 1 battery strings
with 2 battery strings
with 3 battery strings
with 4 battery strings
Ventilation
Airflow full speed
Air flow half speed
Protection grade
Cable entry
2 - 2
a) Easy connection.
b) Enough space to ensure good access when servicing the UPS.
c) Exchange of air sufficient enough to dispel heat produced by UPS.
d) Protection against atmospheric agents.
e) Protection against excessive humidity and very high heat sources.
f) Protection against dust.
g) Compliance with the current fire prevention regulations.
h) Operating environment temperature is within +20° C and +25° C.
The batteries are at maximum efficiency in this temperature range.
Rated power
Service Manual
kVA 10
mm
mm
mm
275
Kg K
m /h
3
15 20 30
1220
530
950
185
365
455
545
forced
600
300
IP 20
Bottom
3x3 UPS Installation
