Chapter 8 - Optional Equipment

Remote Alarm Panel

8.2 - Remote Alarm Panel
The remote indication panel provides duplication of the main functions and operating status of the
UPS control panel LED's, at a distance from the main equipment.

8.2.1 - Remote Alarm Panel connection

The remote signalling panel is provided with its own power supply unit and a connection cable.
The connection is to the M1 tag block on the card and the remote signalling panel.
8.3 -

Upgrade Kit

This Upgrade Kit allows the extension of the output power from the original rating value up to 30kVA by
changing some internal components.
Note: This upgrade must be carried out by a qualified Trained
Additional components may be required (Batteries, Circuit Breakers etc.) depending on the actual in
stallation & unit configuration.
8.4 -

Isolation Transformer

The isolation transformer is a star star configuration and can be connected either in the input or output
side.
This item must be fitted internally in the unit for power up to 20kVA and in an external cabinet for 30kVA.
Different sizes are provided for different power ratings.
8.5 -

Internal Extended Battery Kit

The Kit includes:
8.6 -

Battery Connecting Kit

Is the same as the Internal Extended Battery Kit without the Battery.
8 - 2
Engineer.
1. The Battery (string of 32 batteries 12V each 7.2Ah) Lead Acid Valve Regulated
2. The electrical connections
3. The sustaining frame
Service Manual
3x3 UPS Optional Equipment
Issue 2 - November 2001
