Chapter 8 - Optional Equipment

The following optional equipment is available for the UPS
8.1 -

Second Relay card (Optional)

A Relay card is supplied upon customer demand.
The Relay card functions are the same as the standard card, but the second relay card option provides
a tag block, allowing the duplication of the same signals as the DB9 plug. Therefore, any type of device
(e.g. buzzer alarms, lamps, remote indications, etc.) can be controlled.
The Relay card cannot be fitted with an additional EPO button. To connect several EPO buttons
first connect them in series and then connect to CN3 on the standard Relay card.
For Jumper configuration, please refer to
2
3x3 UPS Optional Equipment
Issue 2 - November 2001
DESCRIPTION
Internal Extended Battery Kit
Battery Connecting Kit
Optional Communications Cards (Relays)
Upgrade Kit 10 to 15kVA
Upgrade Kit 10 to 20kVA
Upgrade Kit 10 to 30kVA
Upgrade Kit 15 to 20kVA
Upgrade Kit 15 to 30kVA
Upgrade Kit 20 to 30kVA
Isolation Transformer 10kVA
Isolation Transformer 15kVA
Isolation Transformer 20kVA
Isolation Transformer 30kVA in Cabinet
Remote Panel
12.
Chapter 2 2. 4 `Setting Standard Relay Interface PCB' on page
PART NUMBER
BATT
BATTCABLE
RELAYCARD
UPGRADE1015
UPGRADE1020
UPGRADE1030
UPGRADE1520
UPGRADE1530
UPGRADE2030
ISOLTX10
ISOLTX15
ISOLTX20
ISOLTX30
8 - 1
