Chapter 9 - Spare Parts

The following list describes the most commonly used part on the (3x3) UPS.
For additional parts and information on the parts location refer to the section 7-4 Component
Identification.
Note: In some case the re-order number for the PCBs and the PCB Label may
For example:
The label on the `silk-screen' of the UPS Monitor Board is CS0077, however the correct re-order
number OSDE0077.
0CEFNC332
0CEVTM2200800
0CPCPA06600450
0CSDRFBYT261P12
0SDE0082
0SDE0070
0SDE0071
0SDE0072–10
0SDE0072–15
0SDE0072–20
0SDE0072–30
0SDE0077
0SDE1074
0SDE0075
0SDE0078
0SDE0079
0SDE0080
0SDE1051
0CEFXV412
0CPCPA08440400
0CATRCM150BU24F
0CATD212420
0CASR212391
0CSSX212413
0CADR210230
0CADRFBYT231
0CADTSSKD82/12
0CESO4063
0CBE1200
3x3 UPS Spare Parts
Issue 2 - November 2001
differ.
Re–order Part Number Description
Fuse 32 A 400 V
Fan 2GDR35 133/190R
Capacitor 60mF 450 V
Diode 60 A 1.200 V
Relay Board
Auxiliary Converter Board
Driver & Feedback Interface
Control Logic Board 10KVA
Control Logic Board 15KVA
Control Logic Board 20KVA
Control Logic Board 30KVA
UPS Monitor Board
Battery Charger Assembly
LCD display
Fan Board
Input filter
EMC/RF Filter Board
Subassembly Module
Fuse 120 A 660 V
Capacitor 4400 mF 400V
IGBT 150 A 1.000 V (Double)
IGBT 200 A 1.200 V (Single)
SCR 91 A 1.200 V
SCR 132 A 1.200 V
Diode 30 A 1.000 V BYT230
Diode 30 A 1.000 V BYT231
Bridge SKD 82/12
Circuit Breaker 63A 4
Sealed Battery 7,2 Ah 12 V
