Powertronix Quasar Service Manual page 12

Specification
BATTERY AUTONOMY TIMES
Configuration Configuration
3 Phase 10kVA
UPS with 1 internal set of batteries
(Standard configuration)
UPS with 2 internal sets of batteries
UPS with 3 internal sets of batteries
UPS with 4 internal sets of batteries
3 Phase 15kVA
UPS with 2 internal sets of batteries
(Standard configuration)
UPS with 3 internal sets of batteries
UPS with 4 internal sets of batteries
3 Phase 20kVA
UPS with 2 internal sets of batteries
(Standard configuration)
UPS with 3 internal sets of batteries
UPS with 4 internal sets of batteries
3 Phase 30kVA
UPS with 3 internal sets of batteries
(Standard configuration)
UPS with 4 internal sets of batteries
Prelim Page x
Approximate Autonomy Time in Minutes
Part N Part Nº
100%
6
17
+ 1 x BATT
28
+ 2 x BATT
41
+ 3 BATT
9
17
+ 1 x BATT
24
+ 2 x BATT
6
11
+ 1 x BATT
17
+ 2 xBATT
6
9
+ 1 x BATT
Service Manual
Stated Load and 25°C
75% 50% 25%
9 17 35
24 40 82
41 66 133
57 94 191
14 24 55
24 40 91
35 56 128
9 17 39
17 28 64
24 40 91
9 17 40
14 24 56
UPS Preliminary Pages
Issue 2 - November 2001
at
10%
115
282
486
600
157
269
398
108
178
263
110
157
