Fuse Replacement

There are two fuses used on the SPU.
Replace fuses only with the same type and rating, as per the table below.
Should a fuse blow, determine the cause before replacing.
To inspect &/or replace a fuse, the clear plastic cover over the SPU's Diagnostic section must
be removed. To do so, gently pry up the center portion of the plastic rivets which fasten the
cover to the SPU's case; be careful not to lose any of the plastic pieces.
After the fuse(s) are replaced, the cover must be re-installed, and remain in place during
normal operation.
Designator
Table 7 – Fuse Replacement Guide
Document PN 29010074 V3.1
ComNav Part Number
F1 60810012
F2 60810009
- 162 -
Care & Maintenance
Generic Description
Manufacturer(s) & Part Number(s)
3.15 A Medium Time Delay, 125V or
better, 5 x 20mm (DIN 41571, IEC 127))
Bussman GMC 3.15A
20A, Non-Time Delay, 125V, ¼"x 1-¼"
Bussman ABC-20
