Mechanical
Environmental
Electrical
Communication
Transducer
10 | StructureScan LSS-1 Installation manual
Specifications
Dimensions: .................................................. See page 12
Weight: ..................................................... 0.8 kg (1.8lbs)
Material: ................................................ Plastic/Aluminum
Operating temperature: ............... -15° - +55°C (5° - 131°F)
Storage temperature: ...............-40° - +85°C (-40° - 185°F)
Waterproof integrity .................................................. IPx7
Notified compliance .......................... CE, FCC, C-Tick, RoHS
Power supply: ....................................................... 12V DC
Voltage input: ...............................................10 - 17 V DC
Fuse: ..................External: 3A Fast Acting Automotive Blade
Transmit power: .......................................... WRMS: 500W
Current drain: ................................................Max: 0.75 A
Ethernet: ............................................................. 3 ports
Shared device support: ..................................................3
Number of devices support: ............................................1
Frequencies: ...................................... 455kHz and 800kHz
WPK: 4000W
Typical: 0.60 A
Inrush: 4.7 A pk
