Required tools and supplies

Drill

LSS-1 Indicator lights

LINK/ACT
1
IND. STATUS
Off
1, 2 and 3
Flashing -
yellow
Off
Sonar On - Green
Flashing -
green
Off
On - Red
On - Green
Power
Slow flashing
- Red/green
Fast flashing -
Red/green
2 mm
(5/64") Phillips screw
Drill Bit driver
2 3 SONAR
No Ethernet communication
(cable unplugged, bad cable or
remote unit not powered)
Ethernet communication is
working (link/active light)
Transducer not connected or
cable/transducer is broken
Transducer detected/locked on to
bottom
Transducer detected/not locked
on to bottom
No power or not switched on
(check yellow wire)
System booting
System operating
Product in factory mode;
Ethernet communication working
Product in factory mode; no
Ethernet communication (cable
unplugged or bad cable)
StructureScan LSS-1 Installation manual | 5
Pencil
POWER
DESCRIPTION
