This document describes how to install the
StructureScan™ LSS-1 and connect the unit to
transducers and display units.
Separate installation instruction for transducers are
included with the transducer package.

Parts included in package

For spare parts and part numbers, see Parts list page
11.
4 | StructureScan LSS-1 Installation manual

Introduction

Item No. Description.
1 LSS-1 Black box module
1 4 pin power cable
1 Fuse, 3A Automotive Type
1 Fuse holder
2 Yellow Ethernet caps
1 Close end crimp connector
4 Phillips stainless steal screws (#8)
1 Warranty
1 This manual
