If the LSS-1 is connected directly to the vessel's battery,
the module will continue to draw power even when it
is not in operation. It is recommended that the yellow
power cable wire be fitted with an optional on/off switch,
allowing the LSS-1 to be powered off when not in use.
A
B
Reference
A
Ethernet cable
B
StructureScan Transducer cable
C
StructureScan Y-cable (option)
For part numbers, see Spare parts and assessories
on page 11.
B
Description
StructureScan LSS-1 Installation manual | 9
A
PWR
B
C
or
