ForwardScan™ Sonar
User guide
Installation
Connecting the transducer
The ForwardScan™ transducer can be connected to the
StructureScan port on the SonarHub or the NSS evo2, leaving the
sonar port open for a CHIRP transducer. Refer to the ForwardScan
installation manual for transducer installation instructions.
Warning:
use the equipment in a manner that will not cause accidents,
personal injury or property damage. The user of this product is
solely responsible for observing safe boating practices.
Warning:
source of
navigation
Sonar performance
The accuracy of the sonar depth display can be affected by many
factors, including the type and location of the transducer and
water conditions. Never use this equipment to gauge depth or
other conditions for swimming or diving.
The choice, location, and installation of transducers and other
components of the system are critical to the performance of the
system as intended. If in doubt, consult your dealer.
To reduce the risk of misusing this equipment, you must read and
understand all aspects of the supplied documentation.
Sharing ForwardScan data
ForwardScan data can be shared with NSO evo2, NSS evo2 or
Zeus
displays by connecting the forward-looking transducer to a
2
SonarHub on your Ethernet network.
You can also connect the transducer to a NSS evo2 to share
ForwardScan data with multi-function displays on your Ethernet
network.
¼ Note:
We do not recommend operating different brands of multi-
function displays on the same network.
It is the owner's sole responsibility to install and
Do not rely on this equipment as your principle
or hazard detection.
ForwardScan |
User Guide
|
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Simrad forwardscan
Summary of Contents for Simrad forwardscan
-
Page 1: Connecting The Transducer
Connecting the transducer The ForwardScan™ transducer can be connected to the StructureScan port on the SonarHub or the NSS evo2, leaving the sonar port open for a CHIRP transducer. Refer to the ForwardScan installation manual for transducer installation instructions. Warning: It is the owner’s sole responsibility to install and... - Page 2 ForwardScan™ forward-looking sonar is a navigational aid that helps you monitor the depth in front of your vessel. ForwardScan features are available in the latest software update for your multi-function display. Refer to your display’s brand website to download the latest update.
- Page 3 Accessing ForwardScan ForwardScan sonar can be displayed full screen or in a multi- panel page. Refer to your operation manual for information about setting up a multi-panel page. ForwardScan setup Critical forward range and Critical depth Critical Forward Range and Critical Depth are user-selected thresholds that define a critical zone forward of your vessel.
- Page 4 Heading extension colors are based on ForwardScan alarm values. Red/Critical Yellow/Warning Green/Safe ForwardScan extension Green Safe Yellow Warning Critical Select ForwardScan in the Extension lines options dialog to view ForwardScan heading extension on the chart panel. ForwardScan | User Guide...
-
Page 5: Noise Rejection
Forward range Controls the forward looking range. Maximum Forward range is 300’ (91 m). Noise Rejection Filters out signal interference and reduces on-screen clutter. Record Used to record ForwardScan sonar logs. Pause Pauses ForwardScan sonar transmissions. ForwardScan | User Guide... - Page 6 History ratio Controls how much of the screen is used to show sonar history on the ForwardScan image. The higher the ratio, the more history will be shown. Point data By default, ForwardScan only shows the bottom. Access the Point data menu to view all sonar data points, or only points (Objects) in the water column.
