4.5.1- Assignments of USB connector terminals USB
Pin
Signal name
1
Vbus
2
D –
3
D+
4
ID
5
GND
Mini -B series USB connector has to be used.
Pin #1
Fig. 13. - EPC1200 USB connector.
EPC1200 SERIES OPERATION MANUAL
Pin #5
18/56
