6 – CONTROL COMMANDS

6.1- COMMAND NOTATION

[Name]
[Format]
[Range]
[Description] It describes the command functionality.
[Notes]
[Defect]
[Reference]
[Examples]

6.2- TERM DEFINITIONS

1) Receiving buffer: It is the buffer that stores the received data (commands and data).
2) Printing buffer.
3) Printable area.
4) Inch
5) MSB
6) LSB
7) Base line.
*1. When the font selected is A type (12x24 dots), this height is 18 dots.
When the font selected is B type (8x16 dots), this height is 14 dots.

Command name.

Coding sequence.
It provides the allowed range for the arguments.
It provides important information in command usage and warnings, if needed.
It provides the default values, if any, for the command parameters.
It lists related commands.
It shows examples on how to use the command.
They are stored temporally in the buffer and are sequentially processed
later.
The printing buffer is a buffer that holds the data of the image to be
printed.
It is the maximum range in which the printing is possible under the
printer specifications. The printable area for this printer is 48mm in the
horizontal direction by the total printable length.
Length unit. One inch is 25.4 millimeters.
Most significant bit.
Least significant bit.
Standard position where the characters are printed. The following
drawing shows the position of normal characters in standard mode:
