Esc T; Select Character Code Table X; Esc Sp; Set Right-Side Character Spacing X - Fenix EPC1200 Operation Manual

ESC t n
[Name] Select character code table
[Format] ASCII
Hex
Decimal
[Range] n = 0, 17
[Description] Selects page n from the character code table.
n(Hex) n(Dec) Page
0
11
[Default] n = 0
[Reference]
APPENDIX E
ESC SP n
[Name] Set right-side character spacing
[Format] ASCII
Hex
Decimal
0 ≤ n ≤ 255
[Range]
[Description] Sets the character spacing for the right side of the character to [n x 0.125 mm
(n x 0.0049")].
[Notes]
• The right side character spacing for double-width mode is twice the normal value.
When characters are enlarged, the right-side character spacing is n times normal
value.
• This command is effective only when sent at the beginning of a line.
[Default] n = 4
[Reference]
APPENDIX A
-

ESC

n
[Name] Turn underline mode on/off
[Format] ASCII
Hex
Decimal
0 ≤ n ≤ 2, 48 ≤ n ≤ 50
[Range]
[Description] Turns underline mode on or off, based on the following values of n:
n(Hex)
0, 30
1, 31
2, 32
[Description] Turns underline mode on or off, based on the following values of n:
[Notes]
• The printer can underline all characters (including right-side character spacing), but
cannot underline the space set by Horizontal tab.
• When underline mode is turned off by setting the value of n to 0 or 48, the following
data is not underlined, and the underline thickness set before the mode is turned
off does not change. The default underline thickness is 1 dot. Changing the
character size does not affect the current underline thickness. Underline mode can
also be turned on or off by using ESC !. Note, however, that the last received
command is effective.
[Default] n = 0
[Reference]
ESC !
ESC ! n

ESC t

n
1B 74
n
27 116
n
0 PC437 (U.S.A., standard Europe)
17 PC866 (Cyrillic)

ESC SP

n
1B 20
n
27 32
n
ESC -
n
1B 2D
n
27 45
n
n(Dec)
0, 48 Turns off underline mode
1, 49 Turns on underline mode (1-dot thick)
2,50 Turns on underline mode (2-dots thick)
EPC1200 SERIES OPERATION MANUAL
Function
30/56
