[Description] Sets the print position to the beginning of print line.
• n specifies the data processing in the print buffer.
n
0
1
GS f n
[Name] Select font for Human Readable Interpretation (HRI) characters
[Format] ASCII
Hex
Decimal
[Range] n = 0, 1
[Description] Selects a font for the HRI characters used when printing a bar code.
n selects a font from the following table:
[Notes]
• HRI indicates Human Readable Interpretation
• HRI characters are printed at the position specified by GS H.
• HRI characters are always printed at X-Scale = 1 and Y-Scale = 1
[Default] n = 1
[Reference]
GS H, GS k
GS H n
[Name] Select print position for HRI characters.
[Format] ASCII
Hex
Decimal
[Range] n = 0, 3
[Description] Selects the print position of HRI characters when printing a bar code.
n selects the print position as follows:
[Notes]
• HRI indicates Human Readable Interpretation.
• HRI characters are printed using X-scale=1, Y-scale=1 and the font specified by GS
f
[Default] n = <02>H
[Reference]
GS f, GS k
GS h n
[Name] Select bar code height
[Format] ASCII
Hex
Decimal
0 ≤ n ≤ 255
[Range]
[Description] Selects the height of the bar code.
n specifies the bar code height in the vertical direction [n x 0.0625 mm (0.0049")].
[Default] n = 160 (10mm)
[Reference]
GS k
Printing position
Sets the print position to the beginning of print line after deleting all data
in the print buffer.
Sets the print position to the beginning of print line after printing all data in
the print buffer.
GS f
n
1D 66
n
29 102
n
n Font
0 Font A (12x24)
1 Font B (8x16)
GS H
n
1D 48
n
29 72
n
n Printing position
0 Not printed
1 Above the bar code
2 Below the bar code
3 Both above and below the code bar
GS h
n
1D 68
n
29 104
n
