SPECIFICATIONS

General
■
• Frequency coverage:
TX
EUR
144–146, 430–440
U.S.A. 144–148, 430–450*
ALL —
* 1 Guaranteed 440–450 MHz only, *
* 3 88.0–108.0 MHz for the USA version.
The SUB band audio signal may be muted, depending on
the combination of operating band and mode.
• Mode:
• Number of memory channels: 554
• Number of BC radio memory channels: 500
• Usable temp. range:
• Tuning steps:
* The selectable steps may differ, depending on the selected fre-
quency band or operating mode.
• Frequency stability:
• Power supply:
• Digital transmission speed: 4.8 kbps
• Voice coding speed:
89
(unit: MHz)
RX
144–146, 430–440
1 108–174* 2 , 380–479* 1
BC Radio (AM): 0.520–1.710 kHz
BC Radio (FM): 76.0–108.0 MHz*
2 Guaranteed 144–148 MHz only
FM, AM (Rx only), DV
(incl. 50 scan edges and 4 call
channels)
–20°C to +60°C; –4°F to +140°F
1, 5, 6.25, 8.33, 9, 10, 12.5, 15, 20,
25, 30, 50, 100, 125 and 200 kHz
±2.5 ppm
(–20°C to +60°C; –4°F to +140°F)
10.0–16.0 V DC for external DC
power, or specified Icom's battery
pack
2.4 kbps
• Current drain
(at 7.4 V DC)
TX (at 5 W)
RX Max. output FM
• Antenna connector:
3
• Dimensions:
(projections not included)
• Weight
(approximately)
Transmitter
■
• Modulation system:
• Output power:
• Max. freq. deviation:
• Occupied bandwidth:
• Spurious emissions:
• Ext. mic. impedance:
:
Less than 2.5 A
Less than 350 mA
(Internal speaker)
Less than 200 mA
(External speaker)
DV Less than 450 mA
(Internal speaker)
Less than 300 mA
(External speaker)
SMA (50 W)
58(W)×105.4(H)×26.4(D) mm;
2.3(W)×4.1(H)×1.0(D) in
: 255 g; 9 oz
(incl. battery pack and antenna)
FM Variable reactance freq.
modulation
DV GMSK reactance freq.
modulation
High 5.0 W, Mid. 2.5 W,
Low2 1.0 W, Low1 0.5 W,
S-Low 0.1 W
(Typical)
±5.0 kHz
(FM wide: approx.)
±2.5 kHz
(FM narrow: approx.)
Less than 6.0 kHz
(DV)
Less than –60 dBc at High/Mid.
Less than –13 dBm at Low2/
Low1/S-Low
2.2 kW
