Owner's Manual
Euromax
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION
INSPECTION REQUIREMENTS IN YOUR AREA.
PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS PELLET FUEL-
BURNING ROOM HEATER. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN
PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
READ AND KEEP THIS MANUAL FOR REFERENCE
This manual is available for free download on the manufacturer's web site. It is a copyrighted
document. Re-sale is strictly prohibited. The manufacturer may update this manual from time to time
and cannot be responsible for problems, injuries, or damages arising out of the use of information
contained in any manual obtained from unauthorized sources.
Printed in Canada
INSTALLATION
AND OPERATION
MANUAL
INSTALLATION BY A
PROFESSIONAL IS STRONGLY
RECOMMENDED
Safety tested according to ULC S627, UL1482
and ASTM E1509 by Intertek Testing Services.
www.enerzone-intl.com
Stove Builder International Inc.
250, rue de Copenhague,
St-Augustin-de-Desmaures (Quebec)
Canada G3A 2H3
Tel.: (418) 878-3040
Fax: (418) 878-3001
45724A
23-06-2014
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Enerzone Euromax
Summary of Contents for Enerzone Euromax
- Page 1 INSTALLATION AND OPERATION MANUAL INSTALLATION BY A Euromax PROFESSIONAL IS STRONGLY RECOMMENDED Safety tested according to ULC S627, UL1482 and ASTM E1509 by Intertek Testing Services. www.enerzone-intl.com Stove Builder International Inc. 250, rue de Copenhague, St-Augustin-de-Desmaures (Quebec) Canada G3A 2H3 Tel.: (418) 878-3040...
- Page 2 THANK YOU FOR CHOOSING THIS ENERZONE PELLET STOVE As one of North America’s largest and most respected pellet stove, wood stove and fireplace manufacturers, Stove Builder International takes pride in the quality and performance of all its products. We want to help you get maximum satisfaction as you use this product.
-
Page 3: Table Of Contents
6.1.10 Filling or Purging Auger Housing ..................... 35 6.1.11 Demo Mode ............................. 36 Stove operation ............................37 7.1 First Startup .............................. 37 7.2 Everyday Startup ............................37 7.3 Running Out of Pellets ..........................37 7.4 Refueling ..............................37 Euromax Pellet Stove Installation and Operation Manual... - Page 4 APPENDIX E: MOBILE HOME INSTALLATION ....................93 APPENDIX F: COMBUSTION AIR SUPPLY ......................95 APPENDIX G: INSTALLING THE DOOR OVERLAY ..................98 APPENDIX H: OPTIONAL HOT AIR DISTRIBUTION KIT (AC01343) ..............99 ENERZONE LIMITED LIFETIME WARRANTY ....................100 Euromax Pellet Stove Installation and Operation Manual...
-
Page 5: Introduction
· Reduces our dependence on fossil fuels · Pellets are a renewable fuel · Wood pellets are made of 100% residual matter (saw dust). This creates added-value from waste that would otherwise end up in a landfill. Euromax Pellet Stove Installation and Operation Manual... -
Page 6: Euromax Specifications
* Burn time and heating capacity may vary subject to location in home, chimney draft, chimney diameter, locality, heat loss factors, climate, selected fuel level, fuel types and other variables. ** This can vary depending on pellet density, length, and diameter. Euromax Pellet Stove Installation and Operation Manual... -
Page 7: Overall Exterior Dimensions
1.3 Overall Exterior Dimensions FRESH AIR INLET EXHAUST Euromax Pellet Stove Installation and Operation Manual... -
Page 8: Part A - Installation
MEDIA (OWNER’S MANUAL, CATALOGUES, FLYERS, MAGAZINES AND/OR WEB SITES). · CONNECT THIS STOVE ONLY TO A LISTED PELLET VENT FOR USE WITH SOLID FUEL OR TO A LINED CHIMNEY CONFORMING TO NATIONAL AND LOCAL BUILDING CODES. Euromax Pellet Stove Installation and Operation Manual... - Page 9 (CANADA), AND ANSI NFPA 211 (USA). · STOVE BUILDER INTERNATIONAL INC. (SBI) GRANTS NO WARRANTY, IMPLIED OR STATED, FOR THE POOR INSTALLATION OR LACK OF MAINTENANCE OF YOUR STOVE AND ASSUMES NO RESPONSIBILITY OF ANY CONSEQUENTIAL DAMAGES. Euromax Pellet Stove Installation and Operation Manual...
-
Page 10: Regulations Covering Pellet Stove Installation
· Make sure the fresh air intake back draft shutter works freely. · Make sure to remove all tools or accessories that have been inserted in the stove for transportation purposes (see following illustration.) Euromax Pellet Stove Installation and Operation Manual... -
Page 11: Clearances To Combustible Material
In addition, you will find important information about your stove (model, serial number, etc.). You will find the certification label on the inner side of the hopper lid of the stove. Euromax Pellet Stove Installation and Operation Manual... -
Page 12: Minimum Clearances To Combustibles
Telco wire provided. You could also want to install the LCD sliding support on the left side of the stove (see Appendix B: Repositioning the LCD Sliding Bracket). Euromax Pellet Stove Installation and Operation Manual... -
Page 13: Ceiling Clearances
EVL (see Section 4.3 Equivalent Vent Length (EVL)). Even the best stove will not function safely and efficiently as intended if it is not connected to a suitable venting system. Euromax Pellet Stove Installation and Operation Manual... -
Page 14: Recommendations
NOTE: Horizontal runs shall not exceed 9 feet. NOTE : Never exceed 30 feet of EVL. Here is an example to help you calculate Equivalent Vent Length. On the following figure the EVL can be calculated like this: Euromax Pellet Stove Installation and Operation Manual... -
Page 15: Termination Location
4.4 Termination Location Termination should not be located so that hot exhaust gases can be a hazard. They can reach temperatures of 500°F (260°C) and cause serious burns. CAUTION: TERMINATION COLLAR (SPARK ARRESTER) IS MANDATORY. Euromax Pellet Stove Installation and Operation Manual... -
Page 16: Permitted Termination Location
Clearance above paved side-walk or a paved driveway located on 84’’ (213 cm) public property 39’’ (100 cm) Clearance to property boundary A vent shall not terminate underneath a veranda, porch, or deck Euromax Pellet Stove Installation and Operation Manual... -
Page 17: Installation Configurations
SPACE, CLOSET OR SIMILAR CONCEALED SPACE OR FLOORS OR CEILING. · INSTALL VENTING SYSTEM AT CLEARANCES SPECIFIED BY THE VENT MANUFACTURER. · THE USE OF A SPARK ARRESTER AT THE END OF THE TERMINATION IS MANDATORY. Euromax Pellet Stove Installation and Operation Manual... -
Page 18: Through Wall Installation (Main Floor Or Basement)
WARNING: TERMINATION SHOULD NOT BE LOCATED SO THAT HOT EXHAUST GASES CAN BE A HAZARD. EXHAUST GASES CAN REACH TEMPERATURES OF 500°F (260°C) AND CAUSE SERIOUS BURNS. SEE SECTION 4.4.1 PERMITTED TERMINATION LOCATION. Euromax Pellet Stove Installation and Operation Manual... -
Page 19: Through Roof Installation
Slide storm collar down until it sits on the flashing. Seal and install vertical roof vent. If required, seal and install a storm collar. Euromax Pellet Stove Installation and Operation Manual... -
Page 20: Through A Factory Built Chimney
CANADA, IT IS NOT MANDATORY BUT IS STRONGLY RECOMMENDED. NOTE: VENTING DIRECTLY IN AN OVERSIZED CHIMNEY AND OMITTING THE USE OF A STAINLESS STEEL LINER CAN AFFECT CHIMNEY DRAFT AND DECREASE STOVE PERFORMANCES. Euromax Pellet Stove Installation and Operation Manual... -
Page 21: Through An Existing Masonry Fireplace
HEARTH. IF OUTSIDE COMBUSTION AIR IS TO BE USED, YOU WILL NEED A PIPE LENGTH SUPERIOR FROM 12 TO 18 INCHES (30 TO 46 CM) OF THE CHIMNEY HEIGHT TO ENSURE A PROPER STOVE BEHAVIOUR. Euromax Pellet Stove Installation and Operation Manual... -
Page 22: Through An Existing Masonry Chimney
9. If desired, once the horizontal pipe is in place, the space between the pipe and masonry may be filled with high-temperature grout. If desired, install a trim collar and use an additional horizontal vent pipe length, if required, to connect the stove to the chimney. Euromax Pellet Stove Installation and Operation Manual... -
Page 23: Part B - Operation
· THIS STOVE SHOULD BE MAINTAINED AND OPERATED AT ALL TIMES IN ACCORDANCE WITH THESE INSTRUCTIONS. FOLLOWING INSTRUCTIONS OF THIS MANUAL MAY CAUSE SMOKE SPILLAGE AND OTHER POTENTIAL HAZARDS. IT IS ALWAYS RECOMMENDED TO INSTALL SMOKE DETECTORS AND FIRE EXTINGUISHER IN A CONVENIENT LOCATION. Euromax Pellet Stove Installation and Operation Manual... - Page 24 · THE STOVE WILL NOT OPERATE DURING A POWER OUTAGE. IF AN OUTAGE DOES OCCUR, CHECK THE STOVE FOR SMOKE SPILLAGE. OPENING A WINDOW WILL PREVENT NEGATIVE PRESSURE AND SMOKE SPILLAGE IN THE ROOM. Euromax Pellet Stove Installation and Operation Manual...
-
Page 25: Zone Heating And How To Make It Work For You
This is called zone heating and it is an increasingly popular way to heat homes or spaces within homes. Euromax Pellet Stove Installation and Operation Manual... -
Page 26: Combustible
Euromax Pellet Stove Installation and Operation Manual... -
Page 27: Stove Controls
The main status page will then display different icons layout depending if the stove is on or not Main status page when the stove is OFF Main status page when the stove is ON Euromax Pellet Stove Installation and Operation Manual... - Page 28 Burn rate parameters Feed screw On/Off button button Burn rate FEED AND START Feed screw adjustment parameters PURGE SCREW Convection blower speed adjustment STOP Feed screw Button to stop button when the feed screw Euromax Pellet Stove Installation and Operation Manual...
-
Page 29: Configuration And Operation Diagram
. Select “TROUBLESHOOT” and then using the arrows, go to page 2. Statistics will be available between page 1 to 3.These statistics can be very useful to a service technician or SBI technical support. Euromax Pellet Stove Installation and Operation Manual... -
Page 30: Adjusting The Combustion Level (Heat Output)
“FUEL QUALITY ADJUSTMENT”. These two (2) settings are available from the “SETUP” page. Note: To obtain optimal results make sure the venting system, heat exchanger and exhaust channels are cleaned before performing any setting changes. Euromax Pellet Stove Installation and Operation Manual... -
Page 31: Combustion Settings And Pilot Settings Depending On Fuel Quality
The “COMBUSTION ADJUSTMENT” will allow you to modify default settings by ±5% for auger motor 1 and ±10% for combustion and exhaust fan. To restore default setting, select “DEFAULT”. Here are some situations where you may want to adjust these components: Euromax Pellet Stove Installation and Operation Manual... -
Page 32: Convection Fan Speed Adjustment
Meanwhile, the convection fan will operate at its highest setting until the stove reaches a safe temperature. Once the stove reaches that temperature, it will return to the previously selected convection fan selection. Euromax Pellet Stove Installation and Operation Manual... -
Page 33: Selecting Manual Or Thermostat Mode
At this time the combustion level will switch into the selected pilot mode until its cycle is completed. When thermostat calls for heat, the icon will change for the one with waves and combustion level will use the last setting. Euromax Pellet Stove Installation and Operation Manual... -
Page 34: Selecting The Pilot Cycle
The pilot cycle begins when temperature set on the thermostat is reached. When the “ALWAYS ON” pilot cycle is selected, the stove will remain on pilot mode until the thermostat calls for heat. Euromax Pellet Stove Installation and Operation Manual... -
Page 35: Filling Or Purging Auger Housing
The auger will turn then the stove will automatically start an ignition cycle. 6.1.10.2 Purge Screw Use this option to empty the auger at the end of the season. When selected, the auger will turn for two minutes Euromax Pellet Stove Installation and Operation Manual... -
Page 36: Demo Mode
To disable the "DEMO" mode, you must press the word "DEMO MODE" followed by "OFF". Euromax Pellet Stove Installation and Operation Manual... -
Page 37: Stove Operation
LCD screen. To restart the stove, close the lid, press the “RESET” button, and then press the “ON/OFF” icon on the Main Status Page. NOTE: Keep hopper lid closed at all times except when refueling. Do not overfill the hopper. Euromax Pellet Stove Installation and Operation Manual... -
Page 38: Shutting Down Procedure
WARNING: IF ANY EXTERNAL PART OF THE STOVE BEGINS TO GLOW RED, THE STOVE IS OVERHEATING. IMMEDIATELY TURN THE STOVE OFF. DO NOT UNPLUG IT AND DO NOT OPEN THE DOOR. UNPLUGING THE STOVE WILL DISABLE ALL THE SAFETY FEATURES OF THE STOVE. Euromax Pellet Stove Installation and Operation Manual... -
Page 39: Maintenance
NONCOMBUSTIBLE SURFACE, WELL AWAY FROM ALL COMBUSTIBLE MATERIALS, PENDING FINAL DISPOSAL. IF THE ASHES ARE DISPOSED OF BY BURIAL IN SOIL OR OTHERWISE LOCALLY DISPERSED, THEY SHOULD BE RETAINED IN THE CLOSED CONTAINER UNTIL ALL CINDERS HAVE BEEN THOROUGHLY COOLED. Euromax Pellet Stove Installation and Operation Manual... -
Page 40: Cleaning The Baffle, The Heat Exchanger And The Combustion Chamber
Using the provided sweeping rod, sweep up and down each exchanger. Make sure you go all the way down to the bottom. Reinstall the access panel to the combustion chamber and tighten the wing nuts. Euromax Pellet Stove Installation and Operation Manual... - Page 41 2) Lift the baffle (B) above its pivots and lower it by gently pulling towards you. To take it out of the door, you must rotate it slowly towards you to avoid hitting the walls of the combustion chamber. Euromax Pellet Stove Installation and Operation Manual...
-
Page 42: Exhaust Channel And Exhaust Blower Maintenance
In order to access the exhaust channels, open the left side decorative panels. Using a Philips or Robertson screwdriver, remove both clean-out traps by unlocking them. Push the screw and give it a counter-clockwise quarter turn. Euromax Pellet Stove Installation and Operation Manual... - Page 43 Locate both openings. Using the provided scraper, remove the dirt in the bottom channel of the heat exchangers. Use an ash vacuum to complete the cleaning operation. Make sure that the gaskets are still in good condition, replace them if needed. (3/16’’ black round gasket) Euromax Pellet Stove Installation and Operation Manual...
-
Page 44: Cleaning The Burn Pot
2. The burn pot simply sits onto the air intake channel. You must lift to remove it from the stove. Two small pins guide the burn pot in place. Make sure that the burn pot is well in place before turning on the stove (as shown in the diagram). Euromax Pellet Stove Installation and Operation Manual... - Page 45 3. If necessary, clean the air intake channel. To reach the air intake channel clean out trap, open the ash drawer access door and remove the ash drawer (A). Euromax Pellet Stove Installation and Operation Manual...
- Page 46 4. Unscrew the wing nut (D) to open the clean out trap (E). Vacuum the combustion residues. 5. Verify that the clean out trap gasket is still in good condition; replace it if needed (3/16’’ black round gasket (AC06815). Euromax Pellet Stove Installation and Operation Manual...
-
Page 47: Ash Removal
2. Vacuum around the ash drawer and at the bottom of the combustion chamber. WARNING: ASH PAN MUST BE IN PLACE AND THE ASH PAN ACCESS DOOR MUST BE KEPT CLOSED AT ALL TIMES WHEN THE STOVE IS IN USE. Euromax Pellet Stove Installation and Operation Manual... -
Page 48: Cleaning The Air Wash System
WARNING: ALWAYS WEAR SUITABLE GLOVES WHILE HANDLING BROKEN GLASS. WARNING: REPLACEMENT GLASS SHOULD ONLY BE PURCHASED FROM AN AUTHORIZED DEALER (SEE “REPLACEMENT PARTS’’ SECTION). TEMPERED GLASS OR ORDINARY GLASS WILL NOT WITHSTAND THE HIGH TEMPERATURES OF THE STOVE. Euromax Pellet Stove Installation and Operation Manual... -
Page 49: Door Gasket Maintenance
The venting system must be in good condition and kept clean. WARNING: IF A SIGNIFICANT LAYER OF CREOSOTE HAS ACCUMULATED (3MM / 1/8” OR MORE), IT MUST BE REMOVED IMMEDIATELY TO ELIMINATE THE RISK OF A CHIMNEY FIRE. Euromax Pellet Stove Installation and Operation Manual... -
Page 50: Dealing With A Chimney Fire
The following sections will help you test each component individually and will also give you many tips in how to solve any problems related to a specific error code. Euromax Pellet Stove Installation and Operation Manual... -
Page 51: Validating Status
Auger motor 2 (will feed the fire with pellets) WARNING: RISK OF ELECTRICAL SHOCK. IF YOU NEED TO MANUALLY TEST, MANIPULATE OR REPLACE ANY COMPONENTS, THE STOVE NEEDS TO BE DISCONNECTED FROM THE WALL OUTLET. Euromax Pellet Stove Installation and Operation Manual... - Page 52 OFF. WITH RED ICONS Pressure switch is closed. This condition is abnormal if the stove is OFF. Pressure switch is open. This condition is abnormal if the stove is in operation. Euromax Pellet Stove Installation and Operation Manual...
-
Page 53: Testing Components
NOTE: IF YOU NEED TO CONTACT YOUR DEALER OR TECHNICAL SUPPORT, MAKE SURE TO HAVE THE MODEL OF YOUR STOVE AND THE SERIAL NUMBER ON HAND. (THEY CAN BE FOUND ON THE CERTIFICATION LABEL INSIDE THE HOPPER LID). Euromax Pellet Stove Installation and Operation Manual... -
Page 54: Blocked Flue
Components). Start the exhaust blower. If the pressure switch square switches from the right column to the left column, it means the pressure switch functions. If not, the pressure switch is defective and needs to be replaced. Euromax Pellet Stove Installation and Operation Manual... -
Page 55: No Fuel
(see Section 9.2 Testing Components) screen and test auger motors. If one of the motors is not running check if motor is defective or if the auger is jammed. HOPPER AUGER Screws Auger and motor assembly gasket Euromax Pellet Stove Installation and Operation Manual... - Page 56 If this is the case, turn on the stove and check the same temperature display. If after 10 minutes, the value has not increased despite the unit is in operation this means that the temperature sensor is disconnected or defective. If the temperature rises, the Euromax Pellet Stove Installation and Operation Manual...
-
Page 57: Failed Ignition
To resolve the situation increase feed rate (see Section 6.1.6 Combustion Settings and Pilot Settings depending on Fuel Quality). Euromax Pellet Stove Installation and Operation Manual... -
Page 58: Defective Igniter Fuse
Make sure the hopper lid is closed. If the motor functions, the auger may be jammed by a foreign object. If no signs of blockage are found, call your dealer or a service technician to perform a complete testing. Euromax Pellet Stove Installation and Operation Manual... -
Page 59: Unit Overheat
The convection blower is defective. Go to the troubleshooting page on the LCD screen and test the convection blower (see Section 9.2 Testing Components). v The convection blower needs maintenance. Carefully clean blower housing and make sure blower louvers are not blocked. Euromax Pellet Stove Installation and Operation Manual... -
Page 60: Hopper Lid Open
If it is, the hopper switch may be faulty. Follow steps in the troubleshooting page (see Section 9.2 Testing Components) and verify the proper function of the safety switch. Replace if necessary. Euromax Pellet Stove Installation and Operation Manual... -
Page 61: Power Loss
The stove can also be affected by other mechanical ventilation systems, causing the same effect as mentioned previously. Using a fresh air intake will prevent negative pressure (see Appendix F: Combustion Air supply). Also, make sure the recommended maintenance schedule has been followed. Euromax Pellet Stove Installation and Operation Manual... -
Page 62: Combustion Air Starvation
This situation may occur in cases where the unit has arrived from outside by a carrier or is subjected to a room temperature too low as in an unheated cottage or a very cold garage. Euromax Pellet Stove Installation and Operation Manual... -
Page 63: Wiring Diagram
10 Wiring Diagram Euromax Pellet Stove Installation and Operation Manual... -
Page 64: Access To Fuses
All fuses are located inside the housing of the electronic board; the housing is on the back of your stove. Unplug your stove, remove the screw and turn the four spring clips to open the housing. Euromax Pellet Stove Installation and Operation Manual... - Page 65 LETTER FUSE FUNCTION AMPERAGE MAIN BOARD FUSE 7.5A CONVECTION BLOWER COMBUSTION BLOWER EXHAUST BLOWER TOP AUGER #1 BOTTOM AUGER #2 IGNITOR Euromax Pellet Stove Installation and Operation Manual...
-
Page 66: Components Location
HOPPER TOUCH SCREEN CONTROL PANEL HOPPER SAFETY SWITCH PRESSURE SWITCH F-160 THERMAL SWITCH POWER CORD RECEPTACLE THERMOSTAT TERMINAL BLOCK COMBUSTION BLOWER/FRESH AIR INTAKE EXHAUST BLOWER BOTTOM AUGER #2 TOP AUGER #1 PC BOARD Euromax Pellet Stove Installation and Operation Manual... -
Page 67: Blower Replacement
Before disconnecting the wire harness from the convection fan assembly, take note of which wire goes where. Unscrew screw (A) with a screwdriver (1). Pull downwards on the convection fan and slide out for complete removal (2). Euromax Pellet Stove Installation and Operation Manual... - Page 68 Unlatch the clamps (C). Remove the backdraft shutter (G) and the gasket (D). Pull the combustion blower (F) and unplug the wire connector from the harness. Remove the plug (E) of the blower. Euromax Pellet Stove Installation and Operation Manual...
- Page 69 EXHAUST BLOWER Remove the left panel. Unplug the connections (A) and (B). Unplug the silicone tube (C). Euromax Pellet Stove Installation and Operation Manual...
- Page 70 Remove the clamp (D). With a Philips screwdriver, unlock and remove the access panel (E). Euromax Pellet Stove Installation and Operation Manual...
- Page 71 Remove the nuts (F) located in the opening of the trapdoor. Remove the duct assembly (G). Euromax Pellet Stove Installation and Operation Manual...
- Page 72 Remove the bolts (H) and nuts (I) to remove the exhaust blower (J) Euromax Pellet Stove Installation and Operation Manual...
-
Page 73: 250 And F-160 Thermal Switch Replacement
14 L-250 and F-160 Thermal Switch Replacement L-250 1. Remove both retaining screws (A) holding the thermal switch support bracket (B). 2. Lift up the support bracket. Rotate the bracket 90° clockwise then pull the bracket toward you. Euromax Pellet Stove Installation and Operation Manual... - Page 74 Remove the faulty thermal switch. Replace new thermal switch (D) underneath the bracket (B) by means of 2 screws (C). F-160 Unscrew both screws (B) and take out the thermal switch F-160 (A). Euromax Pellet Stove Installation and Operation Manual...
-
Page 75: Exploded View And Replacement Parts
15 Exploded View and Replacement Parts SECTION A Euromax Pellet Stove Installation and Operation Manual... - Page 76 SECTION B Euromax Pellet Stove Installation and Operation Manual...
- Page 77 SECTION C Euromax Pellet Stove Installation and Operation Manual...
- Page 78 SECTION D SECTION E Euromax Pellet Stove Installation and Operation Manual...
- Page 79 SECTION F SECTION G Euromax Pellet Stove Installation and Operation Manual...
- Page 80 SECTION H SECTION I Euromax Pellet Stove Installation and Operation Manual...
- Page 81 SECTION J Euromax Pellet Stove Installation and Operation Manual...
- Page 82 LEFT HAND ASH GUIDE PL67104 RIGHT HAND ASH GUIDE SE44132 IGNITOR ASSEMBLY 120V 44146 IGNITER TUBE SE67101 BURN POT PL67175 BAFFLE LOCK PL67172 BAFFLE 30029 CUTTING THREAD SCREW 10-24 TYPE "F" X 3/8" HEX WASHER Euromax Pellet Stove Installation and Operation Manual...
- Page 83 HOPPER STOPPER 44098 HOPPER LID SAFETY SWITCH AC06820 EPDM GASKET KIT 4.5 FT PL67155 SWITCH SUPPORT SE62355 EUROMAX TOUCH SCREEN BOARD (LCD) WITH HOUSING SE67178 LCD BRACKET SE64494 MOTHER BOARD HOUSING 30710 SPRING CLIP 60328 MAIN CONTROL BOARD WIRE HARNESS...
- Page 84 GEAR MOTOR SUPPORT WITH INSULATION 109 30026 THREAD CUTTING SCREW 10-24 F 5/8" HEX WASHER HEAD 110 44109 GEAR MOTOR FOR PELLET STOVE 3.5 RPM 111 30233 NYLON HEX LOCK NUT 10-32 ZINC Euromax Pellet Stove Installation and Operation Manual...
-
Page 85: Appendix A: Horizontal And Vertical Vent Chart
As you can see, the vent termination is clearly outside the allowed configuration zone on the chart because the venting system proposed does not have at least one foot of vertical rise for each foot of horizontal run. Euromax Pellet Stove Installation and Operation Manual... - Page 86 WARNING: To reduce the risk of smoke spillage there should always be at least one foot of vertical rise for each foot of horizontal run. In all cases, at least 3 feet of vertical rise is needed. Euromax Pellet Stove Installation and Operation Manual...
-
Page 87: Appendix B: Lcd Sliding Bracket
(C) using the screws previously removed. Step 2 Remove the screws (D) located on the top edge of the back of the stove. Secure the mounting bracket (C) in place with the same screws. Euromax Pellet Stove Installation and Operation Manual... - Page 88 Take the Telco black wire (E) which is located on the rear bottom panel and plug it into the back of the LCD touch screen interface receptacle. Then, secure the LCD touch screen housing (F) on the rail (A). Euromax Pellet Stove Installation and Operation Manual...
-
Page 89: Appendix C: Flame Caracteristics
To rectify this condition, make sure the stove and the vent system is clean, the pellet being used is dry and increase combustion air flow if necessary. Euromax Pellet Stove Installation and Operation Manual... -
Page 90: Appendix D: Installing A Thermostat (Ac05558)
15 to 20 feet from the stove. To prevent cycling, you should avoid installing the thermostat on a poorly insulated outside wall or directly in front of the stove. THERMOSTAT MINIMUM 15’ Euromax Pellet Stove Installation and Operation Manual... - Page 91 Here is an example of what your thermostat could look like: Connect one wire on “RH” and the other wire on “W”. Red wire jumper can remain installed. For further information refer to the manufacturer’s instructions. Euromax Pellet Stove Installation and Operation Manual...
- Page 92 To do so, open the right hand side decorative panels and disconnect wires (B) and (C) attached to the rear of the terminal block (A) and connect them to the receiver. Euromax Pellet Stove Installation and Operation Manual...
-
Page 93: Appendix E: Mobile Home Installation
For use in a manufactured home in the United States, this pellet stove must be connected to a venting system that meets the requirements of UL 641 standard. A vent system that meets the requirements of UL 103 standard may also be used. Euromax Pellet Stove Installation and Operation Manual... - Page 94 Fresh air intake Pellet pipe length and/or slip section Ceiling support Attic insulation shield Roof flashing Storm collar Pellet pipe length Vertical rain cap Euromax Pellet Stove Installation and Operation Manual...
-
Page 95: Appendix F: Combustion Air Supply
INSULATED PIPE AIR SUPPLY AIR INLET EXTERIOR WALL An insulated 3” inside diameter metallic pipe, either flexible or rigid, must be attached to the fresh air intake (D). Euromax Pellet Stove Installation and Operation Manual... - Page 96 UL- 181-AP foil tape. Make sure that the fresh air intake backdraft shutter (A) functions freely. The fresh air intake backdraft shutter is located in the back of the stove. Euromax Pellet Stove Installation and Operation Manual...
- Page 97 ATTIC, A GARAGE OR ANY CONFINED SPACE. · You can draw air from a ventilated crawl space underneath the floor. · You can draw air directly from an outside wall, behind the stove. Euromax Pellet Stove Installation and Operation Manual...
-
Page 98: Appendix G: Installing The Door Overlay
APPENDIX G: INSTALLING THE DOOR OVERLAY In order to complete the assembly of your Enerzone Euromax, you need to install the door overlay (A). See figure below for installation instructions: 1- Position the overlay (A) on the door frame and secure it in place from behind using the 4 screws (B). -
Page 99: Appendix H: Optional Hot Air Distribution Kit (Ac01343)
APPENDIX H: OPTIONAL HOT AIR DISTRIBUTION KIT (AC01343) *** The hot air distribution kit for Enerzone Euromax will be available soon. Call your local dealer for more detail. *** This is an example only. Hot air distribution kit may differ. -
Page 100: Enerzone Limited Lifetime Warranty
1 year and ceramic fibre blankets. *Pictures required Shall your unit or a components be defective, contact immediately your ENERZONE dealer. Prior to your call make sure you have the following information necessary to your warranty claim treatment: · ·...
