Overview of the Setup Menu in Service Mode

o = Factory setting
x = User-defined setting
Input of the
service password
Setup Device WP1
(Device parameters)
Enter the service
password for access
Setup Application parameters
Fn key function
Device parameters („Device parameters" menu structure depicted below)
Info
Language
Factory settings: all parameters
Off
1
RS-232 ) SBI Standard
SBI Verifiable
o IS-232
ADC-232
Internal A/D converter
configuration
Calibration/
Adjustment
1 ) function will be made available in future
2 ) availability of menu items depends on the software and on the functionality of the connected weighing platform
3 ) menu item not available on scales verified for use in legal metrology
(see „WP1 - Internal" menu 2 ). Rather than A/D converter configuration,
the variant is selected here („Variant").
(see „WP1 - Internal" menu 2 )).
(see „WP1 - Internal - A/D converter configuration" on the page after next).
CAL key function o Ext. cal./adjust.; factory-defined weight
Ext. cal./adjust.; user-defined weight
Ext. lineariz.; factory-def. wt.2)
Ext. lineariz.; user-defined weight
Set preload
Clear preload
Cal key blocked
Cal./adj. sequence Cal. then auto adjust
o Cal. then manual adjust
17
