Option
Enable uPNP
Enable Ping Access on WAN
Enable Web Server Access on WAN
Enable IPsec pass through on VPN connection
Enable PPTP pass through on VPN connection
Enable L2TP pass through on VPN connection

Configuring Static IP connection

If you are a leased line user with a fixed IP address, enter in the IP address, subnet mask, gateway address, and DNS
(domain name server) address(es) provided to you by your ISP.
If your ISP wants you to connect to the Internet using Static IP, follow the instructions below.
From the left-hand Network Settings -> WAN Interface menu. The following page is displayed:
From the WAN Access Type drop-down list, select Static IP setting.
Enter WAN IP Address, WAN Subnet Mask, Default Gateway and DNS which was given by Telecom or by your Internet
Service Provider (ISP).
Click Apply Changes.
Click OK.
From the left-hand Management -> Status menu. The following page is displayed:
If you could see the Attain IP Protocol is shown Fixed IP, you can have the Internet Access right now.
Description
Enable or Disable uPNP
Enable or Disable Ping Access on WAN
Enable or Disable Web Server Access on WAN
Enable or Disable IPsec pass through on VPN connection
Enable or Disable PPTP pass through on VPN connection
Enable or Disable L2TP pass through on VPN connection
WLAN Router
71
