Getting to know the device

Parts Check

In addition to this document, your package should arrive containing the following:
1. Wireless Gateway
2. Ethernet cable
3. CD-ROM containing the online manual
4. QIG
5. Power Adapter

Front Panel

The front panel contains lights called Light Emitting Diodes (LEDs) that indicate the status of the unit.

Front Panel and LEDs

Label Color
POWER green
WLAN green
WPS green
WAN green
LAN
green
1/2/3/4
Function
On: device is powered on
Off: device is powered off
On: WLAN link established and active
Blink: Valid Wireless packet being transferred
Off: WPS link isn't established and active
Blink: Valid WPS packet being transferred
On: WAN link established and active
Off: No LAN link
Blink: Valid Ethernet packet being transferred
On: LAN link established and active
Off: No LAN link
Blink: Valid Ethernet packet being transferred
