WLAN Router
• If you want to use WEP 64bit Hex (10 characters) data encryption, follow the instructions in Configuring WEP
64bit Hex (10 characters) security.
• If you want to use WEP 128bit ASCII (5 characters) data encryption, follow the instructions in Configuring WEP
128bit ASCII (5 characters) security.
• If you want to use WEP 128bit Hex (10 characters) data encryption, follow the instructions in Configuring WEP
128bit Hex (10 characters) security.
• If you want to use WPA1 - Wi-Fi Protected Access 1 (TKIP) Passphrase encryption, follow the instructions in
Configuring WPA (TKIP) Passphrase security.
• If you want to use WPA1 - Wi-Fi Protected Access 1 (TKIP) HEX (64 characters) encryption, follow the instruc-
tions in Configuring WPA (TKIP) HEX (64 characters) security.
• If you want to use WPA2 (AES) - Wi-Fi Protected Access 2 (AES) Passphrase encryption, follow the instructions
in Configuring WPA2 (AES) Passphrase security.
• If you want to use WPA2 (AES) - Wi-Fi Protected Access 2 (AES) HEX (64 characters) encryption, follow the in-
structions in Configuring WPA2 (AES) HEX (64 characters) security.
• If you want to use WPA2 Mixed- Wi-Fi Protected Access 2 (Mixed) Passphrase encryption, follow the instruc-
tions in Configuring WPA2 (Mixed) Passphrase security.
• If you want to use WPA2 Mixed- Wi-Fi Protected Access 2 (Mixed) HEX (64 characters) encryption, follow the
instructions in Configuring WPA2 (Mixed) HEX (64 characters) security.

Configuring WEP 64bit ASCII (5 characters) security

The example set in this section is for 64bit encryption.
From the Encryption drop-down list, select WEP setting.
From the Key Length drop-down list, select 64-bit setting.
From the Key Format drop-down list, select ASCII (5 characters) setting.
From the Default Tx Key drop-down list, select Key 1, Key 2, Key 3 or Key 4 setting.
Type the Default Tx Key to Key 1, Key 2, Key 3, or Key 4. The Default Tx Key is realated to Encryption Key 1, Encryption
Key 2, Encryption Key 3 and Encryption Key 4.
Click Finished.
