Modecom MC-421 User Manual page 113

WLAN Router
4. In the "Local Area Connection Properties" dialog box, select the "Advanced" tab. Disable the Internet Connection
Firewall by de-selecting the entry with the following label:
"Protect my computer and network by limiting or preventing access to the computer from the Internet".
5. Click "OK".
SSDP requirements
You must have SSDP Discovery Service enabled on your Windows XP system to use the UPnP Control point softwa-
re.
SSDP Discovery Service is enabled on a default installation of Windows XP. To check if it is enabled on your system,
look in Control Panel > Administrative Tools > Services).
Installation procedure
To install the Control point software on Windows XP, follow the steps below:
1. In the Control Panel, select "Add/Remove Programs".
2. In the "Add or Remove Programs" dialog box, click the "Add / Remove Windows Components" button.
3. In the "Windows Component Wizard" dialog box, scroll down the list to display the "Networking Services" entry.
Highlight (select) the entry, and click on the "Details" button.
4. The "Networking Services" window is displayed.
The subcomponents shown in the Networking Services window will be different depending on if you are using
Windows XP, Windows XP (SP1), or Windows XP (SP2).
If you are using Windows XP SP2, the Networking Services window will display the following list of sub-compo-
nents:
5. Select the following entries from the "Networking Services" window and then click "OK":
If you are using Windows XP, select:
• "Universal Plug and Play".
113
