Specifications - Andrews FASTflo WH42 Installation Manual, Operation And Maintenance Manual

Continuous flow wall hung balanced flue heaters for natural gas and lpg.
Hide thumbs

Advertisement

Table of Contents
Item
Model Name
Type
Ignition
Minimum Pressure for Maximum flow
Minimum Flow Rate
Dimensions
Weight
Water Holding Capacity
Connection Sizes
Water Inlet
Hot Water Outlet
Gas Inlet
Power Supply
Supply
Consumption
Materials
Casing
Flue Collar
Heat Exchanger
Safety Devices
Accessories
Item
Gas
Consumption (NET)
Hot Water Capacity
Capacity Range
Temperature Settings
Page 57
• Specifications may be changed without prior notice.
• The capacity may differ slightly, depending on the water
pressure, water supply, piping conditions, and water temperature.

Specifications

Installation
Air Supply/Exhaust
Performance
1
2H
1
3P
25°C Rise
58°C Rise
Specification
WH56
Internal, Wall Hanging
Power Flue
Direct Ignition
2.0 bar
3.5 L/min.
61.5 cm(Height) x 46.4 cm(Width) x 24 cm(Depth)
29 kg
1.1 Litre
3/4"
3/4"
3/4"
230V AC (50Hz)
120W
Freeze Prevention 115W
Zincified Steel Plate/Polyester Coating
Stainless Steel
Copper Sheeting, Copper Tubing
Flame Rod, Thermal Fuse, Pressure Relief Valve,
Lightning Protection Device (ZNR),
Electric Leakage Prevention Device, Overheat
Prevention Device, Freezing Prevention Device,
Fan Rotation Detector
Remote Controller, Anchoring Screws
Maximum Performance
62.3 kW
62.3 kW
32 L/min.
13 L/min.
3.5 - 32 L/min.
37 - 48, 50, 55, 60, 65, 70, 75, 80°C
05.9.26, 7:48 PM
LWH56
112W
Minimum Performance
5.0 kW
5.0 kW
57
