15.

Optional Accessories Guide

15-1. Flue Terminal Installation Manual
Model Numbers:
Icons warning of risk level:
WARNING
CAUTION
Directions for Installers
WARNING
• The flue terminal must be installed in accordance with the rules in force.
• Failures and damage caused by erroneous work or work not as instructed in this manual are not
covered by the warranty.
15-1-1. Included Accessories
Part
Flue Terminal
Wall Flange
Tapping Screw
Wall Anchor
FF-100-200
FF-100-400
FF-100-700
Denotes content that may result in personal injury or
property damage if ignored.
This symbol warns of hazards which have the immediate poten-
tial to result in severe or lethal personal injury or fire.
• To operate the water heater properly and safely, comply with this installa-
tion manual and the installation manuals of any other equipment.
• The flue terminal must be installed in accordance with regulation in force.
Shape
Q'ty
1
1
4
4
25
For Installers:
Read this installation guide carefully
before carrying out installation.
The following accessories are included with the unit. Check for any missing
items before starting installation. (They are all attached to the product body.)
Part
Sleeve
Wing Nut
Rounded Wood Screw
Packing (only for products
for wall thicknesses of
370mm to 690mm)
05.10.4, 1:34 PM
Prohibited
Be sure
to do
Shape
Q'ty
1
4
Long: 2
Short: 2
1
25
