15-2. Flue Terminal Installation Manual
Icons warning of risk level:
Directions for Installers
• The flue terminal must be installed in accordance with the rules in force.
• Failures and damage caused by erroneous work or work not as instructed in this manual are not
covered by the warranty.
15-2-1. Included Accessories
Denotes content that may result in personal injury or
property damage if ignored.
This symbol warns of hazards which have the immediate poten-
tial to result in severe or lethal personal injury or fire.
• To operate the water heater properly and safely, comply with this installa-
tion manual and the installation manuals of any other equipment.
• The flue terminal must be installed in accordance with regulation in force.
The following accessories are included with the unit. Check for any missing
items before starting installation. (They are all attached to the product body.)
Rounded Wood Screw
Packing (only for products
for wall thicknesses of
370 mm to 690 mm)
