FireBird System Range Installation Servicing & Operating Instructions page 43

10
SPARE PARTS-BOILER
10-D System Pluming Parts Description
ITEM COMPONENT
No.
1 Automatic air vent
2 Thermostat Pocket
2a Filler Spring
2b Locking Spring
3 Safety Valve
4 Filling loop isolating valve
4a Filling loop hose
4b Filling loop check valve
5 Circulating Pump
6 10 Ltr. Pressure Vessel 50/70
12Ltr. Pressure Vessel 70/90
14 Ltr. Pressure Vessel 90/120
7 Pump Valve 22mm
8 Pump Valve 28mm
9 1/2"drain cock
10 1/4 M/Fm Check Valve
11 Pressure Gauge
11a Pressure Gauge Bracket
11b Pressure Gauge Nut
12 Green Neon Light Indicator
13 Red Neon Light Indicator
14 22mm to 28mm Copper
50-70 70-90 90-120
1 1 1
1 1 1
1 1 1
1 1 1
1 1 1
1 1 1
1 1 1
1 1 1
1 1 1
1
1
1
2 2 1
1
1 1 1
1 1 1
1 1 1
1 1 1
1 1 1
1 1 1
1 1 1
1
41
PART No.
FC 03010
FC 03020
FC 03020a
FC 03020b
FC 03040
FC 03100
FC 03102
FC 0306070
FC 0306090
FC 0306012
FC 03101
FC 0310128
FC 03103
FC 03040CV
FC 03134
FC 03135
FC03136
FC03138
FC 03140
FC 032228
