Variations in nozzle throughput, flue type & draught, oil viscosity etc. may
give results differing from these laboratory performance figures.
DIESEL SETTINGS
Output Range
Btu
70,000 70,000
90,000 75,000
90,000 80,000
90,000 90,000
120,000 110,000
120,000 120,000
150,000 142,000
The above performance figures are based on ideal laboratory test conditions.

Air shutter settings above may need to be revised to take into consideration
difference in resistances between conventional and balanced flue installations.
9
TECHNICAL SPECIFICATION
9-C: RDB 2.2 Range Burner Settings (D).
for Firebird Boiler Range Using RDB 2.2 Burner
Nozzle Pump
Size-Type Pressure bar
0.50 80˚H 12.0 bar
0.50 80˚H 13.5 bar
0.55 80˚S 12.0 bar
0.55 80˚S 13.5 bar
0.65 80˚S 12.5 bar
0.65 80˚S 12.3 bar
0.85 80˚S 13.0 bar
Use flue gas analyser to achieve optimum results.
Head Air
Type
T1 2.0
T3 2.0
T3 2.2
T3 2.8
T5 2.4
T5 3.0
T5 4.0
26
CO2 Air
Box
12% 1
12% 1
12% 1
12% 1
12% 2
12% 2
12% 2
