RTSP over TCP: The RTSP protocol uses a TCP port for data streaming from
the IP camera.
RTSP over UDP: The RTSP protocol uses a UDP port for data streaming from
the IP camera.
D.
For ONVIF and PSIA, modify the Port to 80, else keep the port in default.
E.
Click OK. The camera will be added to the list.
8. Use the up
Connection Information list. The channels will be displayed according to this order.
9. Click Save. The cameras on the Connection Information column will be updated to the
GV-IP Decoder Box and displayed on the monitor.
Note: When the system idles over 30 seconds or resumes after power interruption, the
GV-IP Decoder Box will automatically display channels based on the last successful settings.
Figure 2-18
and down
buttons to move the added channels up and down the
Getting Started
2
21
