2.2 Connecting the GV-IP Decoder Box
Follow the steps below to connect the GV-IP Decoder Box:
1. Connect a display device to VGA connector or High Definition connector for video output.
2. Connect to a standard network cable.
3. Connect to power using the supplied power adapter.
4. Turn the Power switch to ON.
Note:
1. You can only connect the GV-IP Decoder Box to one display device through the High
Definition or VGA connector.
2. The default video output is set to VGA with 1024 x 768 resolutions. If you use a High
Definition monitor, be sure to change the output type. To change the default setting or
configure the output type, see 3.5 Configuring the Account, Storage and Output Type.
Figure 2-5
Getting Started
2
11
