Media Converter/Signal Repeater
NAME
ms430580mAlmModuleGlobFailure
ms430580mAlmSynUnlock
ms430580mAlmDefFuseA
ms430580mAlmDefFuseB
ms430580mAlmLine1TxPwLowWng
ms430580mAlmLine1TxPwrHighWng
ms430580mAlmLine1TxBiasLowWng
ms430580mAlmLine1TxBiasHighWng
ms430580mAlmLine1TempLowWng
ms430580mAlmLine1TempHighWng
ms430580mAlmLine1RxPwrLowWng
MICROSENS GmbH & Co. KG - Küferstraße 16 - 59067 Hamm - Tel. +49 2381/9452 0 - Fax 9452 100 - www.microsens.com
DESCRIPTION
Module Failure: This OID is set on
detection of a failure originating
from the MS module
Synthesizer not locked: This OID
indicates that the frequency
synthesizer is not locked.
Fuse A fail: This OID indicates
that the fuse of the power input
A is in fail condition
Fuse B Fail: This OID indicates
that the fuse of the power input
B is in fail condition
TRSCV 1 Tx Power Low
warning: Warning indicating
that the transceiver output
power of Line 1 is lower than
the threshold value written in
the transceiver EEPROM
TRSCV 1 Tx Power High
warning: Warning indicating
that the transceiver output
power of Line 1 is higher than
the threshold value written in
the transceiver EEPROM
TRSCV 1 Bias Low warning:
Warning indicating that the
transceiver laser bias current of
Line 1 is lower than the
threshold value written in the
transceiver EEPROM
TRSCV 1 Bias High warning:
Warning indicating that the
transceiver laser bias current of
Line 1 is higher than the
threshold value written in the
transceiver EEPROM
TRSCV 1 Temp Low warning:
Warning indicating that the
transceiver temperature of Line
1 is lower than the threshold
value written in the transceiver
EEPROM
TRSCV 1 Temp High warning:
Warning indicating that the
transceiver temperature of Line
1 is higher than the threshold
value written in the transceiver
EEPROM
TRSCV 1 Rx Power Low
warning: Warning indicating
that the transceiver input power
of Line 1 is lower than the
threshold value written in the
transceiver EEPROM
page 9/29
ACTION
Correlate all alarms. If Alarm
persists change the module.
No action information only.
Correlate all alarms. If Alarm
persists change the module.
Correlate all alarms. If Alarm
persists change the module.
Correlate all warnings. Carry out
necessary maintenance
procedures.
Correlate all warnings. Carry out
necessary maintenance procedures.
Correlate all warnings. Carry out
necessary maintenance
procedures.
Correlate all warnings. Carry out
necessary maintenance
procedures.
Correlate all warnings and Alarms.
Carry out necessary maintenance
procedures.
Correlate all warnings. Carry out
necessary maintenance
procedures.
Correlate all warnings. Carry out
necessary maintenance
procedures.
