Microsens 100Base-FX Installation Manual

MICROSENS
Media Converter
Fast Ethernet
100Base-FX / 100Base-TX
Installation Guide
Art.-No.
MS410640 / 41 / 44 / 45 / 46
MICROSENS MICROSENS
fiber optic solutions fiber optic solutions
Internet
www.microsens.com
e-mail
info@microsens.com
Headquarters
MICROSENS GmbH & Co. KG
Kueferstrasse 16
D-59067 Hamm
Germany
Phone +49 (0) 23 81-94 52-0
FAX +49 (0) 23 81-94 52-100
Western Europe
MICROSENS France
ZA Eurocampus Bât J 3
rue de Verdun
F-78590 Noisy le Roi
Phone +33 (0) 1-30 80 21 73
FAX +33 (0) 1-30 80 44 83
Eastern Europe
MICROSENS Poland
ul. Slezna 187/s-2
PL 53-110 Wroclaw
Phone +48 (0) 71-337 16 71
FAX +48 (0) 71-337 16 72
Asia Pacific
MICROSENS GmbH & Co. KG
Asia Pacific Representative Office
#04-51 German Centre
25 International Business Park
Singapore 609916
Phone +65 562 9132
FAX +65 562 9135
Technical Specifications
type Fast Ethernet Media Converter
for the connection of twisted pair
and fiber optic segments.
connectors 1x RJ45 jack
2x ST* connector (MS410641/45)
2x SC connector (MS410640/44/46)
1x power supply jack
cable type
Shielded twisted pair cable
category 5 with RJ45 connectors
max. distance 100 m
Multimode fiber,
fiber type
- duplex ST* (MS410641)
- duplex SC (MS410640)
Single mode fiber, 9/125µm
- duplex ST* (MS410645)
- duplex SC (MS410642/46)
wavelength 1300 nm
max. distance 2 km (MS410640/41)
15 km (MS410644/45)
40 km (MS410646)
LED display Power, Fiber-Link, Fiber-Rcv,
TP-Link, TP-Rcv, Link-Error
power supply external power supply
5V DC / 1 A
operating temp.
0°C to 55°C
storage temp. -20°C to 80°C
rel. humidity
5% to 80% non condensing
* ST is a registered trademark of AT&T
50 or 62,5/125µm
