- Page 1 Gigabit Fiber to Gigabit Fiber (100/1000) Media Converter User Guide MS400230...
- Page 2 Introduction Gigabit Fiber to Gigabit Fiber (100/1000) Media Converter is a cost- effective solution for converting 1000Base-FX to 100/1000Base-FX cabling. It is a standalone converter unit, which allows your network connectivity to be more flexible. Gigabit Fiber to Gigabit Fiber (100/1000) Media Converter will allow you to extend the cabling distance by different transceiver type and its available connection.
-
Page 3: Package Contents
Package Contents Please refer to the package content list below to verify them against the checklist. Modular Gigabit Fiber Converter AC-DC Power Adapter User Guide Compare the contents of your Modular Converter with the standard checklist above. If any item is damaged or missing, please contact your local dealer for service. -
Page 4: Hardware Description
Hardware Description Gigabit Fiber to Gigabit Fiber (100/1000) Media Converter dimensions are 119mm x 85mm x 26mm (W x D x H) Front Panel The front panel of Gigabit Fiber to Gigabit Fiber (100/1000) Media Converter consists of two SFP (Mini-GBIC) slots and 4 LED Indicators (SPD, LK/ACT, and PWR). -
Page 5: Led Indicators
LED Indicators There are 4 diagnostic LEDs located on the Front panel of converter module. They provide real-time information of system and optional status. The following table provides description of the LED status and their meanings. Status Description Green Power on 100/1000 SFP port is operating at speed Green of 1000Mbps... -
Page 6: Rear Panel
DIP-switch The DIP-switch is used to configure operation mode for LLF (Link Loss Forwarding)/LFP (Link Fault Pass-Through) and operation mode for Fiber ports. The default value of Dip-switch is OFF. S/W No Status Description 1000 SFP Force mode 1000 SFP Auto-Negotiation mode LLF Enable LLF Disable 1000 SFP Force mode... - Page 7 Cabling Fiber segment using single-mode connector type must use 9/125μm single-mode fiber cable. The connection distance depends on the fiber transceiver type the user has chosen. Fiber segment using multi-mode connector type must use 50/125 or 62.5/125μm multi-mode fiber cable. The connection distance depends on the fiber transceiver type the user has chosen.
-
Page 8: Troubles Shooting
Troubles shooting Verify that you are using the right power adapter (DC 9V, 0.7A). Please don’t use the power adapter with DC output higher than 9V, or it might burn this converter down. Check the configuration of the DIP-switch. It must be set in the same operation mode with the link partner. -
Page 9: Technical Specification
Technical Specification Gigabit Fiber to Gigabit Fiber (100/1000) Media Converter technical specification is shown as below. IEEE802.3u Standard IEEE 802.3z 1000Base-SX/LX standards IEEE802.3x Flow Control Connector Fiber: 1000 SFP & 100/1000 SFP Fiber Core: Multi-Mode (62.5/125μm, 50/125μm), Single-Mode (9/125μm) Wavelength: 850nm (Multi-mode), Fiber parameters 1310nm (Single-mode) Fiber Distance: Depends on the transceiver... - Page 10 Power, 100/1000 SFP (1000Mbps, LK/ACT), 1000 SFP (LK/ACT) Power Stand-alone (external adapter): DC 9V/0.7A Power 3.3 Watts Consumption Operating C ~ 45 Temperature Operating 10% to 90% (Non-condensing) Humidity Storage C ~ 70 Temperature Dimension 119mm x 85mm x 26mm EMI &...
