- Page 1 RS232/422/485 to Fiber Converter User’s Manual (For MS400131-V2 and MS400132-V2) ©2011, MICROSENS GmbH & Co.KG All rights reserved. Rev. 1.5.1-pk5011...
-
Page 2: Table Of Contents
Table of Contents ......................2 AUTION ................2 LECTRONIC MISSION OTICES 1.INTRODUCTION ..................3 1-1. O ..............3 VERVIEW OF FIBER CONVERTER 1-2. C ....................3 HECKLIST 2. INSTALLATION ..................4 2-1. I ..............4 NSTALLING THE IBER CONVERTER DIN-R .................. -
Page 3: Caution
Caution Circuit devices are sensitive to static electricity, which can damage their delicate electronics. Dry weather conditions or walking across a carpeted floor may cause you to acquire a static electrical charge. To protect your device, always: Touch the metal chassis of your computer to ground the static electrical charge •... -
Page 4: Introduction
1. Introduction 1-1. Overview of fiber converter The fiber optic converter of RS232/422/485 to Fiber Optic is used to extend the distance up to 2Km over the multi-mode fiber or up to 20Km over single-mode fiber. The converter is equipped with multiple interface circuit such as RS232, RS422, RS485 2/4-wire. -
Page 5: Installation
2. Installation 2-1. Installing the Fiber converter Mounting on DIN-Rail ⇒ Remove the four screws on the both sides of the converter. ⇒ Place the converter on the mounting bracket. ⇒ Align the screw holes on the bracket with the holes on the both sides of the converter. -
Page 6: Dip-Switch Settings
DIP-Switch Settings Fig. 5 SW1-1,2 • SW1 (Copper Mode Select) Mode Description RS232 ∗ OFF RS232 mode RS422 4-wire mode RS422-4W (full duplex) RS485 4-wire mode RS485-4W (full duplex) RS485 2-wire mode RS485-2W (half duplex) ∗: Default SW2 (RS-422/RS-485 TERMINATION) •... -
Page 7: Connector
2-3. Connector SUB-DB9 Connector 5 Signal Ground Unused 4 Unused RS422/485-4W RX- 8 3 RS232 TXD or RS422/485-4W TX-, 2W RS422/485-4W TX+ TX/RX- or RS485-2W TX/RX+- 2 RS232 RXD or RS422/485-4W RX+ Unused 6 1 Unused Fig. 6: Female SUB-DB9 connector definition on cable... -
Page 8: Led Description
＊ AC-DC adapter (VOUT +5 VDC) is required. 3. Technical Specifications • Standards: RS-232 TIA/EIA-232 RS-422 TIA/EIA-422 RS-485 TIA/EIA-485 • Network Interface: RS232 (SUB-DB9) RS485/422 (SUB-DB9) SC/ST Fiber Transceiver ∗ Any other fiber model, such as LC, BiDi, etc. is available upon request. - Page 9 • Maximum Cable Distance : Configuration Max. Distance RS232 15m(50ft) RS422/485 1220m (4000ft) Multi-mode Fiber Single-mode Fiber 20km ∗ ＊ Any other distance is upon request. • Fiber Cable: 50/125, 62.5/125, or 100/140 m multi-mode µ 8.3/125, 8.7/125, 9/125 or 10/125 m single-mode µ...
