Microsens Media Converter/Signal Repeater Module User Manual page 23

Media Converter/Signal Repeater
OID
1.3.6.1.4.1.20044.21.2.2.3.8.1
1.3.6.1.4.1.20044.21.2.2.3.8.2
1.3.6.1.4.1.20044.21.2.2.3.8.4
1.3.6.1.4.1.20044.21.2.2.3.8.5
1.3.6.1.4.1.20044.21.2.2.3.8.9
1.3.6.1.4.1.20044.21.2.2.3.8.10
1.3.6.1.4.1.20044.21.2.2.3.8.12
1.3.6.1.4.1.20044.21.2.2.3.16
1.3.6.1.4.1.20044.21.2.2.3.16.1
1.3.6.1.4.1.20044.21.2.2.3.16.4
1.3.6.1.4.1.20044.21.2.3
1.3.6.1.4.1.20044.21.2.3.1
1.3.6.1.4.1.20044.21.2.3.1.28
1.3.6.1.4.1.20044.21.2.3.1.28.1
1.3.6.1.4.1.20044.21.2.3.1.28.2
1.3.6.1.4.1.20044.21.2.3.1.28.3
1.3.6.1.4.1.20044.21.2.3.1.28.4
1.3.6.1.4.1.20044.21.2.3.1.28.7
MICROSENS GmbH & Co. KG - Küferstraße 16 - 59067 Hamm - Tel. +49 2381/9452 0 - Fax 9452 100 - www.microsens.com
Name
ms430580mAlmLine1TrscvAbsent
ms430580mAlmLine1TrscvDdmAbsent
ms430580mAlmLine1HwFail
ms430580mAlmLine1TrscvLsd
ms430580mAlmLine1TrscvDdmWarning
ms430580mAlmLine1TrscvDdmAlm
ms430580mAlmLine1Fail
ms430580mAlmline1AccessioAlm
ms430580mAlmLine1LasFail
ms430580mAlmLine1Los
ms430580mAlmLine
ms430580mAlmLineNurg
ms430580mAlmline2TrscvWarnDdm
ms430580mAlmLine2TxPwLowWng
ms430580mAlmLine2TxPwrHighWng
ms430580mAlmLine2TxBiasLowWng
ms430580mAlmLine2TxBiasHighWng
ms430580mAlmLine2TempLowWng
Access Description
r Line 1 SFP not plugged :This OID
indicates that the transceiver module 2 is
not present.
r DDM supported on Line 1 SFP :This OID
indicates that the transceiver module 1
does not support Digital Diagnostic
Monitoring Functions
r Line 1 HW Failure :This OID indicates a
hardware failure on the Line 1
r Line 1 SFP optical TX ON :This OID
indicates the optical output power is off
on Line 1
r Warning DDM on Optical Module 1: This
OID indicates a warning is present
coming out of optical interface DDM on
Line 1
r Alarm DDM on Optical Module 1: This
OID indicates an alarm is present coming
out of optical interface DDM on Line 1
r Line 1 Failure: This OID indicates a
failure on the Line 1
r Line 1 SFP Tx Failed: This OID indicates
that the transmitter fails for the
transceiver plugged into the Line 1 (this
alarm reports the transmitter failure
alarm generated by the transceivers)
r Loss of Optical signal on Line 1: This OID
indicates that no signal is present on the
transceiver 1
r TRSCV 2 Tx Power Low warning:
Warning indicating that the transceiver
output power of Line 2 is lower than the
threshold value written in the
transceiver EEPROM
r TRSCV 2 Tx Power High warning:
Warning indicating that the transceiver
output power of Line 2 is higher than
the threshold value written in the
transceiver EEPROM
r TRSCV 2 Bias Low warning: Warning
indicating that the transceiver laser bias
current of Line 2 is lower than the
threshold value written in the
transceiver EEPROM
r TRSCV 2 Bias High warning :Warning
indicating that the transceiver laser bias
current of Line 2 is higher than the
threshold value written in the
transceiver EEPROM
r TRSCV 2 Temp Low warning:Warning
indicating that the transceiver
temperature of Line 2 is lower than the
threshold value written in the
transceiver EEPROM
page 23/29
