Media Converter/Signal Repeater
OID
1.3.6.1.4.1.20044.21.3.2.18
1.3.6.1.4.1.20044.21.3.2.19
1.3.6.1.4.1.20044.21.3.2.20
1.3.6.1.4.1.20044.21.3.3
1.3.6.1.4.1.20044.21.3.3.24
1.3.6.1.4.1.20044.21.3.3.25
1.3.6.1.4.1.20044.21.3.3.26
1.3.6.1.4.1.20044.21.3.3.27
1.3.6.1.4.1.20044.21.3.3.28
1.3.6.1.4.1.20044.21.6
1.3.6.1.4.1.20044.21.6.1
1.3.6.1.4.1.20044.21.6.1.0
1.3.6.1.4.1.20044.21.6.1.0.1
1.3.6.1.4.1.20044.21.6.1.0.9
1.3.6.1.4.1.20044.21.6.1.0.13
1.3.6.1.4.1.20044.21.6.1.4
1.3.6.1.4.1.20044.21.6.1.4.1
MICROSENS GmbH & Co. KG - Küferstraße 16 - 59067 Hamm - Tel. +49 2381/9452 0 - Fax 9452 100 - www.microsens.com
Name
ms430580mMesrline1TxBias
ms430580mMesrline1TxPower
ms430580mMesrline1RxPower
ms430580mMesrLine
ms430580mMesrline2Temperature
ms430580mMesrline2Volt
ms430580mMesrline2TxBias
ms430580mMesrline2TxPower
ms430580mMesrline2RxPower
ms430580mcontrolsWrite
ms430580mCtrlOther
ms430580mCtrlsynth0
ms430580mCtrlConfLoad
ms430580mCtrlConfFlash
ms430580mCtrlConfClear
ms430580mCtrlsynth4
ms430580mCtrlCorrelatOn
Access Description
r Line 1 SFP Laser bias: This OID gives
the bias value of the transceiver Line
1, read from the
DDM (Digital Diagnostic Monitoring)
(Unit = mA)
r Line 1 SFP Transmitted Power: This
OID gives the transmit power value of
the transceiver Line 1, read from the
DDM (Digital Diagnostic Monitoring)
(Unit = dBm)
r Line 1 SFP Received Power: This OID
gives the receive power value of the
transceiver Line 1, read from the DDM
(Digital Diagnostic Monitoring) (Unit
= dBm)
r Line 2 SFP Temperature :This OID
gives the temperature of the
transceiver Line 2, read from the DDM
(Digital Diagnostic Monitoring) (Unit
= °C)
r Line 2 SFP Power Supply: This OID
gives the voltage of the transceiver
Line 2, read from the DDM (Digital
Diagnostic Monitoring) (Unit = V)
r Line 2 SFP Laser bias: This OID gives
the bias value of the transceiver Line
2, read from the DDM (Digital
Diagnostic Monitoring) (Unit = mA)
r Line 2 SFP Transmitted Power :This
OID gives the transmit power value of
the transceiver Line 2, read from the
DDM (Digital Diagnostic Monitoring)
(Unit = dBm)
r Line 2 SFP Received Power: This OID
gives the receive power value of the
transceiver Line 2, read from the DDM
(Digital Diagnostic Monitoring) (Unit
= dBm)
r/w Load Configuration Tables: When set
this enables loading from flash
configuration1 into the module.
r/w Write Configuration Tables: This bit
saves the current configuration of the
module as configuration in the flash.
r/w Clear Configuration Tables :This bit
clears the configuration tables from
configuration in the flash.
r/w Enable Alarm Correlation: This OID
enables the alarm correlation in the
MS module.
