Media Converter/Signal Repeater
MS430580MTraps
Name
Description
ms430580mPortaTrapNotUrgentGoesOn
Not urgent Line 1 fault is activated
ms430580mPortaTrapNotUrgentGoesOff
Not urgent Line 1 fault disappeared
ms430580mPortaTrapUrgentGoesOn
Urgent Line 1 fault is activated
ms430580mPortaTrapUrgentGoesOff
Urgent Line 1 fault disappeared
ms430580mPortaTrapCritGoesOn
Critical Line 1 fault is activated
ms430580mPortaTrapCritGoesOff
Critical Line 1 fault disappeared
ms430580mPortbTrapNotUrgentGoesOn
Not urgent Line 2 fault is activated
ms430580mPortbTrapNotUrgentGoesOff
Not urgent Line 2 fault disappeared
ms430580mPortbTrapUrgentGoesOn
Urgent Line 2 fault is activated
ms430580mPortbTrapUrgentGoesOff
Urgent Line 2 fault disappeared
ms430580mPortbTrapCritGoesOn
Critical Line 2 fault is activated
ms430580mPortbTrapCritGoesOff
Critical Line 2 fault disappeared
ms430580mPowerTrapUrgentGoesOn
Urgent power fault is activated
ms430580mPowerTrapUrgentGoesOff
Urgent power fault disappeared
Software Management
Hardware Reset
A Hardware reset may be performed on the MS430580M. This operation is performed
by extracting and re-inserting the MS430580M in the M430500M Chassis. The following
MICROSENS GmbH & Co. KG - Küferstraße 16 - 59067 Hamm - Tel. +49 2381/9452 0 - Fax 9452 100 - www.microsens.com
Bindings
ms430580mAlmPortaTrscvDdmWarning
ms430580mtrapBoardNumber
ms430580mAlmPortaTrscvDdmWarning
ms430580mtrapBoardNumber
ms430580mAlmPortaTrscvDdmAlm
ms430580mtrapBoardNumber
ms430580mAlmPortaTrscvDdmAlm
ms430580mtrapBoardNumber
ms430580mAlmPortaFail
ms430580mAlmPortaHwFail
ms430580mtrapBoardNumber
ms430580mAlmPortaFail
ms430580mAlmPortaHwFail
ms430580mtrapBoardNumber
ms430580mAlmPortbTrscvDdmWarning
ms430580mtrapBoardNumber
ms430580mAlmPortbTrscvDdmWarning
ms430580mtrapBoardNumber
ms430580mAlmPortbTrscvDdmAlm
ms430580mtrapBoardNumber
ms430580mAlmPortbTrscvDdmAlm
ms430580mtrapBoardNumber
ms430580mAlmPortbFail
ms430580mAlmPortbHwFail
ms430580mtrapBoardNumber
ms430580mAlmPortbFail
ms430580mAlmPortbHwFail
ms430580mtrapBoardNumber
ms430580mAlmDefFuseA
ms430580mAlmDefFuseB
ms430580mtrapBoardNumber
ms430580mAlmDefFuseA
ms430580mAlmDefFuseB
ms430580mtrapBoardNumber
page 15/29
Action
Consult Alarms. Correlate warnings
originating from the line. Carry out
necessary maintenance
procedures.
No Action.
Consult Alarms. Correlate alarms
originating from the line. Carry out
necessary maintenance
procedures.
No Action.
Consult Alarms. Correlate alarms
originating from the MS module.
Carry out necessary maintenance
procedures.
No Action.
Consult Alarms. Correlate warnings
originating from the port. Carry out
necessary maintenance
procedures.
No Action.
Consult Alarms. Correlate alarms
originating from the port. Carry out
necessary maintenance
procedures.
No Action.
Consult Alarms. Correlate alarms
originating from the MS module.
Carry out necessary maintenance
procedures.
No Action.
Consult Alarms. Correlate alarms
originating from the MS module.
Carry out necessary maintenance
procedures.
No Action.
